Research on the Hardware-in-the-Loop Simulation for High Dynamic SINS/GNSS Integrated Navigation System

Abstract:

In the process of developing guided munitions, ground test can only verify the performance of integrated navigation system in low dynamic condition, and its costly and risky to use means of authentication such as flight test and throw experiment. This paper proposes a kind of hardware-in-the-loop simulation (HILS) scheme with tri-axial turntable for verifying the performance of navigation system in high dynamic condition. It respectively uses quaternion method and four-sample rotation vector algorithm as attitude updating algorithms for comparison. On the basis of analyzing the characteristics of some tactical missile and the HILS system, the error sources of integrated navigation system in the simulation with turntable and that without turntable are discussed in detail. The results of HILS show that integrated navigation system is of good performance under high dynamic environment; moreover, for the fiber optic gyroscope (FOG) inertial measurement unit (IMU) which outputs angular rate, quaternion method is better than four-sample rotation vector algorithm.

• Periodical: Advanced Materials Research (Volumes 846-847)
• Pages: 378-382
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.846-847.378
• Online since: November 2013
• Authors: Hao Ran Lei*, Shuai Chen, Yao Wei Chang, Lei Jie Wang
• Keywords: Hardware-in-the-Loop Simulation, High Dynamic, Integrated Navigation System, Tri-Axial Turntable

References

[1] Zhanlong Yang, Hang Chen. Hardware-in-the-loop Simulation with Acoustic Coupling for Underwater Acoustic Detection System. [J]. Proceedings of 4th ICCSIT2011, IEEE, Vol. 7, (2011).

[2] Yanbin Liu, Guang Jin. Development of Hardware-in-the-loop Simulation Technology. [J]. Optics, Mechanics & Electronics Information, (2003)1, 27-32.

[3] Ningjun Gao, Zhiyong Zhang, and Chao Gao, et al. Research of Distributed Hardware-in-the-loop Simulation System Based on Guided Weapons. [J]. Command Control & Simulation, 32(2010)6, 74-79.

[4] Ruisheng Sun, Zhuo Liang, and Rui Hu, et al. Analysis of a Hardware-in-the-loop Simulation of GB's Guidance and Control System with Orthogonal Test. [J]. Acta Armamentarii, 29(2008)7, 883-886.

[5] Yanwu Xie. Design of Hardware-in-the-loop Simulation System for Infrared Imaging Homing Missile. [J]. Computer Measurement & Control, 21(2013)2, 394-395.

[6] Dehua Xu. Research on the Key Technologies of Real Time Hardware in the loop Simulation System. [D]. Heilongjiang: Harbin Engineering University, 2005, 23-37.

[7] Guangjun He, Baoquan Li, and Lifang Ma. Development of Hardware-in-the-loop Simulation of SINS/GPS Integrated Navigation System. [J]. Computer Simulation, 23(2006)7, 268-271.

[8] Lu Han, Zhanrong Jing, and Jingmei Zhang, et al. Numerical Simulation of Strapdown Inertial Navigation System. [D]. Journal of Xi'an Technological University, 29(2009)2: 163-167.

[9] Leigang Wang, Lidu Yang, Yang Zhang. Pointing Error Analysis of Three-axis Simulation Missile Turntable. [J]. Computer Simulation, 26(2009)11, 73-76.

[10] Zhihong Deng, Mengyin Fu, Jiwei Zhang, et al. Inertial Components and Inertial Navigation System. [J]. Beijing, Science Press, 2012: 220-223.

[11] Zhenglong Deng. Inertial Technology. [M]. Heilongjiang, Harbin Institute of Technology Press, 2006, 165-171.
