Vibration Analysis and Research on Air Bearing Block of CMM

Abstract:

This paper describes the CMM main error sources and their classification, Dynamic error of flotation blocks vibration due to a single degree of freedom is for analysis, the use of the Navier - Stokes equations and mathematical modeling equations of Newtonian mechanics, the establishment of finite element model and simulation analysis, the movement of the coordinate measuring machine in the dynamic stress and deformation and vibration conditions for the design of coordinate measuring machine provides a new approach.

• Periodical: Advanced Materials Research (Volume 852)
• Pages: 543-546
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.852.543
• Online since: January 2014
• Authors: Xiao Qing Zhao
• Keywords: Coordinate Measuring Machine, Dynamic Stress, Error, Vibration

References

[1] Zhang Guowei, coordinate measuring machines, Tianjin University, Tianjin University Press, (1999).

[2] NI Zhen-hua, vibration Mechanics, Xi'an Jiaotong University Press, 1986. 12.

[3] Dong Chensong, Guoxiong andMuyu Hai, China Mechanical Engineering, CHINA MECHANICAL ENGINEERING, 1998, 7(9).

[4] Li Yuzhu, Yuan Ming Shun, fluid mechanics, Higher Education Press, 1998, 6.
