Forecast on Upsetting Crack Based on Numerical Simulation

Abstract:

To improve the forging quality and avoid longitudinal cracks on forging surface, critical hole expansion ratio of ductile failure of metallic materials micromechanics was adopted as the criterion to judge whether crack occurs during upsetting, and the upsetting FEA model of 5CrNiMo hot die steel was established based on FEM software DEFORM-3D. The dangerous points on forging surface which crack may occur easily were analyzed based on the calculating results of the metal hole expansion ratio, and the influence of forgings shape on upsetting cracks were researched. The results show that when the relative reduction of the center point on the forgings surface exceeds 65%, the first crack occurs during upsetting; the shape coefficient can be used as the conditions and basis for cracks forecast by establishing the comparison expression between shape coefficient and hole expansion ratio during upsetting.

• Periodical: Advanced Materials Research (Volume 852)
• Pages: 561-566
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.852.561
• Online since: January 2014
• Authors: Yan Bo Fan, Qin Xiang Xia, Ming Ke Lv, Xue Zhi Zhao, Yu Lian Du
• Keywords: Forging Surface Longitudinal Cracks, Hole Expansion Ratio, Hot Die Steel, Numerical Simulation, Upsetting

References

[1] China Society for Technology of Plasticity, CMES. Forging and Stamping. China Machine Press, Beijing，(2008).

[2] Valery. Simulation of Forging in Flat and V-Shape Dies[C]. The 14th International Forging Meeting. Wiesbaden, Germany, 2000: 449-457.

[3] Lv Y. Forging Defect Analysis and Countermeasures. China Machine Press, Beijing, (1998).

[4] Zheng C Q. Cracked and non-cracked body injury unified theoretical research anthology. Northwestern Polytechnical University Press, Xi'an, (1991).

[5] Rice J R， Tracey D M．On the ductile enlargement of voids in triaxial stress fields．J．Mech．Solid．1969，(17)：201-217.

[6] Ren Y L, Zhu L, Nie S M, et al. On Upsetting Conditions of Large Forgings without Cylinder Surface Cracking , 2009，20（8）: 883-886.

[7] Wang C P, Zhang J G, Yang X Y, et al. Expand ratio of cavity forecast on the hot forming crack position of large- size head with flange, Pressure vessel technology. 2010, 27(11): 18-24.

[8] Xia Q X, Xiang K, Zhao X Z, et al. Research on forging method of marine long-shaft heaving forging, Forging & Stamping, 2013, 38(1): 12-16.

[9] Zheng C Q, Zhou L, Zhang K S. Micromechanics metal ductile failure and its application[M]. Beijing: National Defense Industry Press.

[10] Zhu Z Y. Performance datasets of hot die steel (continued Ⅰ). Materials for Mechanical Engineering, 2001, 25(2)：40-42.
