Optimum Design of Remote Controller Back Shell Injection Mould Based on Flow Simulation

Abstract:

Taking the remote controller back shell for example, the flow process of the injection molding including filling, packing, holding and cooling was simulated by using the process technology of Moldflow software, the best gate location and the information of weld lines, trapped gas, fill time, pressure and temperature were analyzed. At the same time, the product defects during the injection was predicted, the cause of defects and influence factors was analyzed, the mould design parameters were adjusted, the design of the mould was optimized. It realized mass production of the product.

• Periodical: Advanced Materials Research (Volume 852)
• Pages: 567-572
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.852.567
• Online since: January 2014
• Authors: Jian Ming Hong
• Keywords: Flow Simulation, Injection Mould, Moldflow, Optimum Design

References

[1] Yang Weimin, Ding Yumei, Xie Pengcheng. New Technology of Injection Molding [M]. Beijing: Chemical Industry Press, 2008: 472-492.

[2] Hong Jian-Ming. Improvement air traps defect of power button based on flow simulation of Moldflow, [J]. China Plastics 2013, 27(03): 87-91.

[3] Hong Jianming. Design of Injection Mould of Worm with Metal Insert [J]. Engineering Plastics Application 2009, 37(7): 63-65.

[4] Shan yan. Moldflow Mold Analysis Technology Basis [M]. Beijing: Tsinghua University Press, 2005: 90-117.

[5] Peter Jones. The Mould Design Guide [M]. Shorpshire: Smithers Rapra Technology Limited, 2008: 355-364.

[6] Wu Xiao-lian, Lu Jun. Analysis of Injection Molding of Cell Phone Shell Based on Moldflow, [J]. Plastics Industry 2012, 40(06): 50-52.

[7] Jerry M. Fischer. Handbook of Molded Part Shrinkage and Warpage [M]. NY: William Andrew Publishing, 2002: 133-138.
