Research on Inductive Power Charging Device of Unmanned Ground Vehicle

Abstract:

It is important to charge accumulator automatically on unmanned ground vehicles. A kind of inductive power charging system, with rotary type coupler and series-resonant power converter of full bridge, is designed. The working progress of resonant circuit and main circuit is simulated. The result of experiments shows that the simulation model of main circuit agrees well with practice and can instruct design of power converter in the future. The efficiency of power transferring decreases with coupler air gap increasing. The designed inductive charging device can charge accumulator with constant current while the air gap is 1.2 mm.

• Periodical: Advanced Materials Research (Volume 852)
• Pages: 660-664
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.852.660
• Online since: January 2014
• Authors: Zhi Ning Li, Jian Wei Chen, Ying Tang Zhang, Gang Yin
• Keywords: Circuit Simulation, Inductive Power Transfer, Series-Resonant Power Converter, Unmanned Ground Vehicles
