Pro/ENGINEER and 3DS Max Combined with Virtools for Virtual Reality Application

Abstract:

At present, the most widespread model of development for the Virtools technology is 3DS Max + Virtools, to a certain extent, this limits the application of virtual reality technology in mechanical industry. In order to solve this problem, take the machinery slider as an example, set up entity model using Pro/ENGINEER (Proe), then render the model through the 3DS Max, finally import it into the Virtools platform for interaction design, realize importing and transformation of model from mechanical CAD software to Virtools development platform.
