TQLZ Self-Balance Vibrating Screen Static and Modal Analysis

Abstract:

A simplified model of self-balance screen was constructed by using SolidWorks, and then imported into the Simulation to analysis its structure and modal. The stress distribution, deformation and structural natural frequency, mode shapes under static loads of the self-balance vibrating screen were calculated to provide theoretical basis for the following analysis of the dynamic characteristics and structure optimization design of vibrating screen.
