Comparison of Ni_0.8Cu_0.2O_x Anode Material Prepared with Sol-Gel Method and Ni_0.8-Cu_0.2-Coated YSZ Composite Anode Material Prepared with Polyol Method

Abstract:

This paper elaborates Ni_0.8-Cu_0.2-coated YSZ material prepared with the hard template method and the polyol method, with the composition and microstructure being analyzed with X-Ray Diffraction (XRD) and Scanning Electron Microscope (SEM). With YSZ as electrolyte material, LSM as cathode material and Ni_0.8Cu_0.2O_x prepared with sol-gel method and partially-tubular YSZ material coated with Ni_0.8-Cu_0.2 as anode material, electrolyte-supported cells were prepared, and with methane as fuel gas, the electrical properties of cells were determined. It was indicated that Ni and Cu prepared with traditional sol-gel method and YSZ were granular structure, and the contact area was small relatively. The new material prepared was a mixture of Ni, Cu and YSZ, where the YSZ was of partial fiber-tubular structure and the Ni and Cu granules were applied to the interior and exterior surfaces of the structure. It was able to effectively increase the contact surface of catalytic metal and electrolyte, which added to the three phase boundary of the SOFC anode and lead to power performance 80% higher than the former.

• Periodical: Advanced Materials Research (Volume 853)
• Pages: 116-122
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.853.116
• Online since: December 2013
• Authors: Hong Xin You*, Bin Qu, Lei Cao
• Keywords: Anode Material, Hard Template Method, Metal Cu, Metal Ni, Polyol Method, SOFC, Sol-Gel Method

References

[1] MOGENSEN M, SAMMES N M, TOMPSETT G A. Physical, chemical and electrochemical properties of pure and doped ceria [J]. Solid State Ionics, 2000, 129(1–4): 63-94.

DOI: 10.1016/s0167-2738(99)00318-5

[2] Tang Z Y, Pang L Z, Nan J M. The research of electrochemical performance of La(1-x)SrxNi(1-y)FeyO3 type perovskite bifunctional oxygen electrode [J]. Acta Chimica Sinica, 2005, 63(5): 363-71.

[3] UN J H, LIM T H, NAM S-W, et al. Mechanism of partial oxidation of methane over a nickel-calcium hydroxyapatite catalyst[J]. Applied Catalysis A: General, 2006, 312(0): 27-34.

DOI: 10.1016/j.apcata.2006.06.020

[4] TRIANTAFYLLOPOULOS N C, NEOPHYTIDES S G. The nature and binding strength of carbon adspecies formed during the equilibrium dissociative adsorption of CH4 on Ni–YSZ cermet catalysts[J]. Journal of Catalysis, 2003, 217(2): 324-33.

DOI: 10.1016/s0021-9517(03)00062-9

[5] HEO Y-H, LEE J-W, LEE S-B, et al. Redox-induced performance degradation of anode-supported tubular solid oxide fuel cells[J]. International Journal of Hydrogen Energy, 2011, 36(1): 797-804.

DOI: 10.1016/j.ijhydene.2010.10.038

[6] M. G C, M. P M, S. O B J, et al. Synergistic effects of Ni[1-x]Co[x]-YSZ and Ni[1-x]Cu[x]-YSZ alloyed cermets SOFC anodes for oxidation of hydrogen and methane fuels containing H.

DOI: 10.1016/j.jpowsour.2008.05.002

[2] S [J]. Anglais, 2008, 183(1): 26-33.

[7] RINGUED A, FAGG D P, FRADE J R. Electrochemical behaviour and degradation of (Ni, M)/YSZ cermet electrodes (M=Co, Cu, Fe) for high temperature applications of solid electrolytes[J]. Journal of the European Ceramic Society, 2004, 24(6): 1355-8.

DOI: 10.1016/s0955-2219(03)00564-8

[8] RESTIVO T A G, DE MELLO-CASTANHO S R H. Nickel-Zirconia cermet processing by mechanical alloying for solid oxide fuel cell anodes [J]. Anglais, 2008, 185(2): 1262-6.

DOI: 10.1016/j.jpowsour.2008.08.082

[9] Wang J, Li C, Xu B. The basic principle of sol-gel method, development and application [J]. Chemical Industry and Engineering, 2009, 03: 273-277.

[10] UEDA W, SADAKANE M, OGIHARA H. Nano-structuring of complex metal oxides for catalytic oxidation[J]. Catalysis Today, 2008, 132(1–4): 2-8.

DOI: 10.1016/j.cattod.2007.12.012

[11] WANG F H, GUO R S, WEI Q T, et al. Preparation and properties of Ni/YSZ anode by coating precipitation method [J]. Materials Letters, 2004, 58(24): 3079-83.

DOI: 10.1016/j.matlet.2004.05.047

[12] DONG D, WU Y, ZHANG X, et al. Eggshell membrane-templated synthesis of highly crystalline perovskite ceramics for solid oxide fuel cells[J]. Journal of Materials Chemistry, 2011, 21(4): 1028-32.

[13] Xu W, He B L, Liu G R, et al. The preparation of nanometer nickel by microwave method [J]. Journal of South-Central University of Nationalities(JCR Science Edition), 2006, 25(04): 1-4.

[14] You H X, Abuliti A, Ding X W, et al. Reactions of Low and Middle Concentration Dry Methane over Ni/ YSZ Anode of Solid Oxide Fuel Cell[J]. Journal of Power Sources, 2007, 165(2): 722-727.

DOI: 10.1016/j.jpowsour.2006.12.041
