Upon Power Loses due to Current Harmonics in a Fotovoltaic System, Opperating at Maximum Power Point

Abstract:

Photovoltaic panels (PF), combined with lead-acid battery (AE), are increasingly used, to produce electricity. To work in maximum power points, between (PF) and (AE) is interposed a static converter (DC-DC), which is a harmonic pollution source. Within the paper there are calculated the power losses, due to current harmonics, of a photovoltaic system working at its maximum power. Photovoltaic system works at its maximum power, if in the electronic system there is permanently voltage control among solar battery terminals.

• Periodical: Advanced Materials Research (Volume 853)
• Pages: 352-357
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.853.352
• Online since: December 2013
• Authors: Calin Chioreanu*
• Keywords: Current Harmonics, Dc-Dc Converter, Lead-Acid Battery, Photovoltaic Panel, Power Losses

References

[1] V. Quaschning - Understanding Renewable Energy Systems, ISBN 1-84407-128-6 , London Carl Hanser Verlag GmbH & Co KG, (2005).

[2] S. Tian, M. Hong, and M. Ouyang, An Experimental Study and Nonlinear Modeling of Discharge I-V Behavior of Valve-Regulated Lead-Acid Batteries, IEEE Trans. Energy Convers., vol. 24, no. 2, pp.452-458, June (2009).

DOI: 10.1109/tec.2008.2001447

[3] N. Kakimoto, H. Satoh, S. Takayama, and K. Nakamura, Ramp-Rate Control of Photovoltaic Generator With Electric Double-Layer Capacitor, IEEE Trans. Energy Convers., vol. 24, no. 2, pp.465-473 June (2009).

DOI: 10.1109/tec.2008.2001580

[4] M. Kolhe, Techno-Economic Optimum Sizing of a Stand-Alone Solar Photovoltaic System, IEEE Trans. Energy Convers., vol. 24, no. 2, pp.511-519 June (2009).

DOI: 10.1109/tec.2008.2001455

[5] N. Kakimoto, S. Takayama, H. Satoh, and K. Nakamura, Power Modulation of Photovoltaic Generator for Frequency Control of Power System, IEEE Trans. Energy Convers., vol. 24, no. 4, pp.943-949, December (2009).

DOI: 10.1109/tec.2009.2026616

[6] Y. Lembeye, V. Dang Bang, G. Lefevre, and J. Ferrieux, Novel Half-Bridge Inductive DC-DC Isolated Converters for Fuel Cell Applications, IEEE Trans. Energy Convers., vol. 24, no. 1, pp.203-210, March (2009).

DOI: 10.1109/tec.2008.2006553

[7] Shu-xian Lun, Cun-jiao Du, Gui-hong Yang, Shuo Wang, Ting-ting Guo, Jing-shu Sang, Jia-pei Li, An explicit approximate I–V characteristic model of a solar cell based on padé approximants, Solar Energy, Volume 92, Pages 147-159 (June 2013).

DOI: 10.1016/j.solener.2013.02.021

[8] V. Pires, J. F. Martins, D. Foito, Chen Hão, A Grid Connected Photovoltaic System With a Multilevel Inverter and a Le-Blanc Transformer, International Journal of Renewable Energy Research (IJRER), volume 2, No: 1, pp.84-91, (2013).
