Electric Field Calculation Software for Epoxy Resin Casting Dry-Type Transformer Based on the VB

Abstract:

In the paper, combining the advantages of interface design of VB and secondary design of ANSYS, the electric calculating software for epoxy resin casting dry-type transformer was designed. In the procedure of designing transformer, designers only need to input the structure parameters and electrical parameters of the transformer, which would be transferred to ANSYS Parametric Design Language (APDL) program automatically. Then, the different loading conditions and post-procedure programs can be selected. Furthermore, VB calls ANSYS from the background program and reads the APDL file to calculate electric field distribution. Finally, the case analysis verifies that the software can establish the finite element model automatically and calculate the electrical field distribution under any fundamental frequency voltage and lighting surge.

• Periodical: Advanced Materials Research (Volumes 860-863)
• Pages: 2203-2207
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.860-863.2203
• Online since: December 2013
• Authors: Jia Zhu Xu, Ke Zhou*, Ji Liang Yi, Si Wei Liu, Xun Xiao
• Keywords: APDL, Electric Field Analysis, Epoxy Resin Casting Dry-Type Transformer, Finite Element Model (FEM), Lighting Surge

References

[1] Changzeng Zhang, Chaohui Long, Qinggan Zeng, ＂Analysis of Environmental Protection Characteristics of Expoxy Resin Casting Dry Type Transformer＂, Transformer Journal, Vol40, issue7, 1-3, 2003. (In Chinese).

[2] Xuefeng Ni, Hao Lin, Yihua Wu, ＂Cause and Resolution for Surface Discharge in Dry-type Reactors＂, High Voltage Engineering Journal, Vol25, issue3, 57-59, 1999. (In Chinese).
