Research of Integrated Power Propulsion System Simulation Based on PSCAD

Abstract:

Modeling and simulation of generator, frequency converter, motor, propeller of integrated power system in PSCAD environment respectively, finally form a complete system, which contains the diesel engine and speed regulation system, generator and excitation system, motor and vector control system. Establish the propeller model as motor load by Fortran language. The motor load constantly changing, traditional PI controller parameters are not easily adjusted in real time, SNAPID controller based on the error changes in the changing, complete SNAPID controller in MATLAB environment and call MATLAB continually, the control effect of speed is improved in the process of marine propulsion. Finally simulate typical working condition of system, the simulation results show that propeller shaft torque is smaller when grading operating, the influence of electric propulsion system is smaller and conducive to maintaining the stability of the system.

• Periodical: Advanced Materials Research (Volumes 875-877)
• Pages: 1939-1943
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.875-877.1939
• Online since: February 2014
• Authors: Hai Lan, Xin Zhao, Jie Meng
• Keywords: Fortran, Hysteresis Current Control, MATLAB, Propeller, PSCAD, SNAPID, Vector Control (VC)

References

[1] Yun Liu, Shaozuo Xu: Overview on marine synthesize electric propulsion system , Diesel engine (2004).

[2] Xianfeng Chen, Zhibing Shu, Yingkai Zhao: Simulation analysis on hysteresis-band current-control of PMSM position servo system based on vector control, Electric drive(2006).

[3] Swarn S. Kaisi, Om Nayak: Ship electrical system simulation, IEEE Electric Ship Technologies Symposium(2005).

DOI: 10.1109/ests.2005.1524654

[4] Yusheng Li, Rui Chen: Simulation of marine diesel generator based on PSCAD, Marine electric &Electronic technology (2010).

[5] Zhuopeng Zhao, Shifeng Jia: Research on control and simulation of PWM inverter with current hysteresis loop tracking (2011).

[6] Shitao Zhang，Feng Yang，Qian Hao, Research and simulation of single neuron PID controller, Mechanical engineering and automation(2009).

[7] Jinkun Liu, Advanced PID control MATLAB simulation, Publishing House of Electronics Industry(2011).

[8] Lin Yang, Research of marine electrical network stabilization influenced by the electric propulsion system, Harbin engineering university(2009).

[9] Bin Luo，Hui Chen，Haibo Gao, Propeller load characteristic simulation in marine electrical propulsion system, Journal of Guangzhou marine college(2009).
