Design and Development of Instrument for Measuring Torque and Shear Modulus for Material Research

Abstract:

An Instrument for measuring torque and shear modulus based on flat coil element for material research has been developed. Flat coil element was made from a thin epoxy with number of coils 30 and outer diameter of 3 cm. Working principle of the sensor is based on position change of a disturb element which attached to test shaft in front of the flat coil. The change of position will change the total inductance of the sensor system. The change of inductance is measured using LC oscillator by measuring its resonant frequency. An F/V converter converts the resonance frequency into voltage. The flat coil is used to measure the change of angle of the developed torque instrument. Using microcontroller ATMEGA16 the developed instrument can be controlled and work automatically. The developed instrument can measure torque and shear modulus with relative error less than 3%

• Periodical: Advanced Materials Research (Volumes 875-877)
• Pages: 2123-2127
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.875-877.2123
• Online since: February 2014
• Authors: Ratih Kumalasari, Mitra Djamal, Edi Sanjaya
• Keywords: Flat Coil Element, LC Oscillator, Sensor, Shear Modulus, Torque

References

[1] M. Djamal, R. Kumalasari, Indonesian patent pending, Reg. Nr. P00201200438, Indonesia (2012).

[2] M. Djamal, E. M. Sundari, R. Kumalasari, Ramli: Development of Mechanical Sensors Based on Flat Coil Element, International Conference on Circuits, Systems, Communications, Computers and Applications (CSCCA '12), Latest Advance in Information Science, Circuits & Systems, G. Enescu University, Iasi, Romania, June 13-15, 2012, pp.248-253.

[3] R. Kumalasari: Desain dan Pembuatan Alat Ukur Momen Gaya Berbasis Sensor Koil Datar Menggunakan Mikrokontroler ATMEGA16, Master Thesis, Faculty of Mathematics and Natural Sciences, ITB, (2012).

[4] Halliday, et al: Fundamentals of Physics, extended, Sixth Edition. New Delhi, Wiley India (2006).

[5] H.L. Sang, et al: Torque Sensor Calibration Using Virtual Load For a Manipulator, Sandiego, Proceedings of the 2007 IEEE/RSJ International Conference on Intelligent Robots and System (2007).

DOI: 10.1109/iros.2007.4399345

[6] H.D. Young, Sears and Zemansky's: University Physics, with modern physics. 12th ed. Adisson Willey (2007).

[7] M. Djamal: Development of vibration sensor based on flat coil element, ITB, (2009).

[8] M. Djamal, Ramli, S. Satira, Suprijadi, International Journal of Mathematical Models and Methods in Applied Sciences (IJMMMAS), Issue 3, Vol. 5, 2011, pp.550-573.

[9] I. S Grant, et al : Electromagnetism. New Delhi , Thompson Press (1990).

[10] J.D. Krauss, Electromagnetics Mexico : Mc Graw Hill International Book Company (1982).

[11] L. Umar: Studi Awal Sensor Getaran Berdasarkan Prinsip Induktif, Bandung, Master Thesis, Dept. Of Physics, ITB (1996).

[12] Wiyanto : Elektromagnetika. Yogyakarta, Graha Ilmu (2008).

[13] H. Ardianto: Pemrograman Mikrokontroler AVR ATmega 16. Bandung, Informatika Bandung (2008).
