Theoretical Analysis of Electrical Properties of GaAs Substrate-Nanowire P-N Junction

Abstract:

We theoretically analyze the electrical properties of GaAs substrate-nanowire p-n junction using Technology Computer Aided Design (TCAD). The results show that GaAs nanowire-substrate p-n junction exhibits clear diode behavior which has been confirmed in some experiments. Increasing NWs doping concentration and diameter or shortening NWs length can enlarge the total current after the diode is conducted. Total current through p-n junction is approximately linearly proportional to NWs growth density. The substrate-nanowires p-n junction has smaller current than that of substrate-layer p-n junction, which implies the superiority of NW structure. These results constitute an important progress for experimental researches on nanowire-integrated devices.

• Periodical: Advanced Materials Research (Volumes 875-877)
• Pages: 394-398
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.875-877.394
• Online since: February 2014
• Authors: Wen Li Chen, Xia Zhang, Xin Yan, Jun Shuai Li, Yong Qing Huang, Xiao Min Ren
• Keywords: Electrical Properties, GaAs, Nanowire, p-n Junction

References

[1] Jun Hu, Yang Liu and Alex Maslov: Proc. of SPIE Vol. 6468, 64681E (2007).

[2] Andrey Lysov, Sasa Vinaji and Matthias Offer: Nano Res. Vol. 4(10) (2011), p.987.

[3] G.E. Cirlin, A.D. Bouravleuv and I.P. Soshnikov: Nanoscale Res. Lett Vol. 5(2010), pp.360-363.

[4] Josef A. Czaban, David A. Thompson and Pay R. Lapierre: Nanoletters Vol. 9(1) (2009), pp.148-154.

[5] X. F. Duan, Y. Huang and R. Agarwal: Nature Vol. 421(2003), pp.487-490.

[6] P. Nguyen, H. T. Ng and T. Tamada: Nano Letters vol. 4(2004), pp.651-657.

[7] A Lysov, M Offer and C Gutsche: Nanotechnology Vol. 22(2011).

[8] I. Regolin, C. Gutsche and A. Lysov: Journal of Crystal Growth Vol. 315(1)(2011), pp.143-147.

[9] Chiristoph Gutsche, Andrey Lysov and Ingo Regolin: Nanoscaled Research Letters Vol. 6(2011), p.65.
