The Design and Preparation of X Band Absorbing Insulation Coatings

Abstract:

According to the principle of electromagnetic wave absorption, functionally reforming thermal insulating materials for building, through designing and theoretically simulating of the λ/4 model, using carbon fiber film, the article has successfully prepared insulation coatings for X-band electromagnetic wave absorption. Result shows, with the thickness of 3.0 mm in 8 ~ 12 GHz band, 100% of bandwidth below-10 dB can be reached. New materials can be used such as the surface of the thermal insulation of buildings and X-band electromagnetic interference protection.

• Periodical: Advanced Materials Research (Volumes 881-883)
• Pages: 1065-1069
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.881-883.1065
• Online since: January 2014
• Authors: Dong Wei Chen, Fan Wu, Xue Hong Yu, Chang Jun Liao, Wan Jun Hao*, Ming Ming Wang, Ying Ying Yi, Hui Chao Zhao, Yi Feng Dong
• Keywords: Absorption of Electromagnetic Wave, Coating, Preparation, X Band

References

[1] W.J. Hao, Measure and countermeasures of electromagnetic radiation[R]. Miyagi prefecture OTC Research Report , 2001: 3-10.

[2] S.H. Wang, F. Wen and W.J. Hao, Electromagnetism Pollution and Protection Materials for Electromagnetic Radiation[J]. Environmental Science and Technology, 2006, 12(29): 96-98.

[3] W.J. Hao, Application of paint absorbing electromagnetic wave in city construction[J], Science and technology of foreign building materials, 2004, 5(4): 74-76.

[4] H. suzuki etc, Development of gypsum boards for perfect of Communication environmental[J]. Industrial Materials, 2006, 54(6): 40-44.

[5] K. Ansayi etc, Cement Absorber , Industrial materials[J]. 2000, 48(12): 56-60.

[6] O. Hoshimoto, Technologies and Applications of Wave Absorber. Tokyo: CMC Press, 2004: 10-30.

[7] O. Hashimoto，Introduction to Wave Absorber, Tokyo: Morikita press in Japan, 1997: 10-30.

[8] S.H. Liu, J.M. Liu and X.L. Dong, Electromagnetic wave shielding and absorbing material. Beijing: Chemical Industry Press, 2007: 50-80. (in Chinese).

[9] Y. nayitou, EMWave Absorber, Tokyo: Omu press in Japan, 1987 : 20-40.

[10] H.Y. Liu,W. Sun Y.J. Feng etc, Improving the S-band Performance of the Microwave absorbing Material Utilizing Frequency Selective Surface[J]. Journal of Microwaves, 2006, 22(3): 10-13.

[11] C.M. Sun D.W. Chen W.J. Hao, The Research on Thinning of S-band Boards for the Electromagnetic-pollute Protection in Buildings[J]. China Material Technology and Equipment, 2013, 6: 66-68.

[12] D.L. Zhao, Radar absorption property and mechanism of carbon fiber and carbon fiber composites[J]. New Carbon Materials, 2001, 16（2）: 62-69.
