The Influence of Orthotropy and Taper Angle on the Compressive Strength of Composite Laminates with Scarfed Holes

Abstract:

The residual strengths of laminated composites containing notches or holes depend on the characteristic dimension of the notches as well as the laminate properties. This paper presents an experimental and computational investigation of the effect of orthotropy as well as scarf notch angles on the compressive strength of composite laminates made of seven different stacking sequences with the number of plies ranging between 20 and 24. Specimens containing scarfed holes of different scarf angles (6° and 10°) and straight holes of two different diameters (3.175mm and 6.35mm) were tested for comparison. Experimental results of the compressive strengths, normalised by the respective un-notched compressive strength show that the extent of orthotropy, defined as the laminate stiffness ratio along and perpendicular to the main loading direction, has a major effect. Computational modelling was carried out using the finite element method to quantify the residual strength; in which ply fracture is modelled using the continuum damage mechanics approach.

• Periodical: Advanced Materials Research (Volumes 891-892)
• Pages: 178-184
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.891-892.178
• Online since: March 2014
• Authors: Mitesh Patel*, Stephen Daynes, Chun H. Wang
• Keywords: Composite, Continuum Damage Mechanism, Finite Element Analysis (FEA), Notch Size, Scarf Hole
