Effects of Growth Temperature on the Structural Properties of Zinc Oxide Nanograins Deposited by RF Magnetron Sputtering

Abstract:

Nanograins zinc oxide (ZnO) with c-axis preferred orientation was deposited on glass substrates by RF magnetron sputtering. It was performed with a ZnO target with 99.999% purity at RF power of 200 W. The deposition was carried out in argon and oxygen ambient at the ratio flow-rates of 10 and 5 sccm respectively, with total deposition time of 1 hour. The films were grown atgrowth temperatures were specified at RT, 100, 200, 300, 400 and 500°C. The effects of the growth temperature on the ZnO structural property was investigated by x-ray diffraction (XRD). The best ZnO crystalline quality obtained at growth temperature, T_G of 300°C was further characterized by field emission scanning electron microscopy (FESEM) and atomic force microscopy (AFM).

• Periodical: Advanced Materials Research (Volume 895)
• Pages: 500-504
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.895.500
• Online since: February 2014
• Authors: N. Ameera, Ahmad Shuhaimi Abu Bakar, S. Najwa, K.M. Hakim, M. Mazwan, M. Sobri, M.H. Mamat, M.Z. Musa, M. Rusop
• Keywords: Nanostructure, RF Magnetron Sputtering, Zinc Oxide (ZnO)
