Design and Implementation of Intelligent Tester for LED Backlight LCD Display Driving Power

Abstract:

In accordance with the requirement of LED LCD driving power test and the basic principle of digital DC electronic load and combined with the trend of intelligentization, miniaturization, communication of electronic load, a new scheme of intelligent tester for LED LCD driver power based on PIC is proposed. It implements working modes of setting current, testing voltage, testing current, testing frequency, multi-channel transmission etc. Intelligent testing for ten states of LED LCD's four outputs under two power mode is supported. It can also send test data to upper computer for analysis with RS485 bus.

• Periodical: Advanced Materials Research (Volume 898)
• Pages: 863-866
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.898.863
• Online since: February 2014
• Authors: Dun Fan Ye*, Xin Liu, Ya Min Li, Meng Yan Zhang
• Keywords: Driving Power, Electronic Load, PIC, RS485 Bus

References

[1] W. H. Li, Y. Xie: Exploration into the Investigative Status Quo of the Electronic Analog Load, Journal of Xinyu College, Vol. 10 (2005) No. 2, pp.47-49.

[2] Z. G. Liu, J. H. He: Design and Realization of Energy Feedback Type Electronic Power Load Based on Current-Type PWM Rectifie, Transactions of China Electrotechnical Society, Vol. 19 (2004) No. 6, pp.74-77.

[3] C. A. Yang, W. Wang and L. Zhao: Experimental Research of CC E-load Based on Feedback Control, Modern Electronics Technique, (2006) No. 14, pp.127-128.

[4] F. S. Pan, J. F. Zhao and X. Wang: Study of High Power AC Electronic Load, Power Electronics, Vol. 40 (2006) No. 1, pp.97-100.

[5] C. Wang, Z. G. Liu and S. M. Shen: System Design of Modularized Electronic Power Load, Electrotechnical Application, Vol. 25 (2005) No. 9, pp.54-57.

[6] Y. Luo: PIC Single Chip Application System Development Typical Examples (China Electric Power Press, China 2005).
