FE Analysis of Hot Strips’ Temperature Distribution in Laminar Cooling Process

Abstract:

The temperature distribution of the hot-rolled strip in the ROT cooling process was calculated and analyzed using ABAQUS in this paper. The complicated heat transfer coefficients of hot strip considering the position effects of top and bottom nozzles, and the non-uniform heat transfer situation along the width direction were defined by user subroutine. The simulation results were in good correlation with test results. It’s helpful for further analysis to improve the temperature distribution uniformity and the simulation accuracy for FE model, and guide the on-site production.

• Periodical: Advanced Materials Research (Volume 900)
• Pages: 647-650
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.900.647
• Online since: February 2014
• Authors: Yu Qing Zheng*, Jing Yu Cui
• Keywords: FE Model, Hot Strip, Laminar Cooling, Temperature Distribution

References

[1] Hibbitt, et. al., 2001, ABAQUS Analysis User's Manual, V6. 7: pp.578-637.

[2] G.D. Wang, et. al., 1990, Japan Iron and Steel Association: Strip Rolling Theory and Practice. Beijing: China Railway Press: pp.37-40.

[3] Y. Miyake, et. al., 1980, Device and System for Controlled Cooling for Hot Strip Mill. Transactions ISIJ, 20: pp.496-500.

DOI: 10.2355/isijinternational1966.20.496

[4] H. Yoshida. 1984, Analysis of Flatness of Hot Rolled Steel Strip after Cooling. Transactions ISIJ, 24: pp.212-215.

DOI: 10.2355/isijinternational1966.24.212

[5] Ishioka, et. al., 1994, Slab Control Review of the Basis of Cooling Process. Materials and Processes, 7: pp.404-407.

[6] Ishioka, et. al., 1993, Foundation Special Under- side the Basis of Slit Nozzle Cooling. Materials and Processes, 6: pp.435-447.

[7] Michiharu, et. al., 1993, Comparison of the Plate Underside Surface Cooling Method. Materials and Processes, 6: pp.438-441.
