Study on the Influence of Deformation of the Slipper of Axial Piston Pump under High Pressure on Oil Film Structure

Abstract:

The stress and strain of the slipper of 35 MPa high pressure axial piston pump are analyzed by the finite element analysis method, and the following facts are revealed: in spite of the fact that the slipper can satisfy the use requirement in the aspect of stress, whereas, in the aspect of strain, the deformation of the bottom of the slipper increases with the pressure increase, and the deformation of the slipper has reached the order of magnitude of the oil film thickness under 35 MPa working pressure. Therefore, when the slipper pair of 35 MPa high pressure axial piston pump is designed and its oil film performances are studied, the influence of deformation of the slipper on the oil film structure must be considered comprehensively. The results of this study can provide some guides for developing 35 MPa high pressure axial piston pump.

• Periodical: Advanced Materials Research (Volume 900)
• Pages: 734-737
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.900.734
• Online since: February 2014
• Authors: Huai Chao Wu*, Yun Liu Yu
• Keywords: Axial Piston Pump, Deformation, Oil Film, Slipper Pair

References

[1] B. Wang, H. Zhou, H.Y. Yang. Journal of mechanical engineering, Vol. 45(11)(2009), pp.113-118. (In Chinese).

[2] L. Zhang, H.Y. Xiang, F. Zhao, et al. Machine tool & Hydraulics, Vol. 35 (6) (2007), pp.120-122. (In Chinese).

[3] C.J. Hooke, K.Y. Li. Proceedings of the institution of mechanical engineers, Part C: Journal of mechanical engineering science, Vol. 203 (5) (1989), pp.343-350.

[4] J.M. Bergada, J.M. Haynes, J. Watton. Tribology Transactions, Vol. 51 (2008), pp.469-482.

[5] M.M. Liu, H. Shi, X.F. Huang. Journal of shenyang aerospace university, Vol. 28 (4) (2011), pp.22-26. (In Chinese).

[6] W.Q. Hu. Machine tool & Hydraulics, Vol. 41 (10) (2013), pp.102-104. (In Chinese).
