Photoluminescene and Fourier Transform Infrared Measurement of Undoped Diamond-Like Carbon Thin Films by Direct Current – Plasma Enhanced Chemical Vapour Deposition

Abstract:

Undoped diamond like thin films have been prepared by using Direct Current - Plasma Enhanced Chemical Vapour Deposition system. A potentially diamond thin films was fabricated in the presence of gas mixture which accordance to the ratio CH₄ (1%) + H₂ (39%) + Ar (60%). The substrate temperature was controlled and adjusted from 300 °C to 500 °C in a vacuum chamber with the optimum pressure of 4 X 10^-1 Torr. The films were characterized by X ray diffraction microscopy (XRD), Photoluminescene spectroscopy (PL) and Fourier Transform Infrared (FTIR) spectroscopy. It shows that, XRD pattern shown that the film was formed in the amorphous phase with a high fraction of sp³ hybridization. Luminescene band shows the peak position at (3.16 eV and 2.94 eV), (3.16 eV and 2.95 eV), (3.17 eV and 2.93 eV) and (3.26 eV) for the films deposited at 300, 350, 400 and 500 °C, respectively. The structural configuration of film obtained which corresponding to the sp³ hybridization of C H bonding gives a most significant result at approximately 760 cm^-1 region was presented.

• Periodical: Advanced Materials Research (Volume 903)
• Pages: 102-107
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.903.102
• Online since: February 2014
• Authors: Jackie Chen Keng Yik*, Karim bin Deraman, Ong Wai Kit, Wan Nurulhuda Wan Shamsuri, Rosli Hussin
• Keywords: Amorphous Carbon, Diamond-Like Carbon (DLC), Direct Current Plasma Enhanced Chemical Vapour Deposition (DC-PECVD)

References

[1] Chang Hyun Lee, K.S.L., Boron-doped amorphous diamondlike carbon as a new p-type window material in amorphous silicon p-i -n solar cells. Applied physics, 72. (1997).

DOI: 10.1063/1.120659

[2] Wen-Jen Liu , X. -j.G., Chi-Lung Chang, Jhih-hao Lu, Diamond-like carbon thin films synthesis by low temperature atmospheric pressure plasma method. Material science and Engineering. 517 (2009) pp.4229-4232.

DOI: 10.1016/j.tsf.2009.02.047

[3] Steven M. Smith, S.A.V., Harland Tmpkins, Andy Hooper, A. Alec Talin, Joseph Vella, Nitrogen - doped plasma enhanced chemical vapor deposited (PECVD) amorphous carbon: processes and properties. Thin Solid Films, (2001) pp.163-169.

DOI: 10.1016/s0040-6090(01)01425-0

[4] Z. Yin, Z.A., B.X. Yang, F.W. Smith, Optical properties and microstructure of CVD diamond films. Diamond and Related Materials, 6 (1997) pp.153-158.

DOI: 10.1016/s0925-9635(96)00740-6

[5] Karim Deraman, S.S., Bakar Ismail, N.E. Ahmad, R. Hussin, W. Nurulhuda W. Shamsuri, M. Nor M. Yusof, Khaidzir Hamzah, Optical properties od diamond-like carbon thin fillms deposited by DC-PECVD. Journal of Fundamental Sciences, 7 (2011) pp.1-5.

DOI: 10.11113/mjfas.v7n1.201

[6] Edemir A, D.C., Modern Tribology handbook. 2000: B. Bhusan (ed. ) CRC Press. 871-908.

[7] Street, R.A., Technology and Applications of Amorphous Silicon. Springer Series in Materials Science, 37. (2000).

[8] Bruno. G, C.P., Madan. A, Plasma Deposition of Amorphous Silicon-Based Materials. Plasma-Materials Interactions, (1995).

DOI: 10.1016/b978-012137940-7/50001-2

[9] Robertson, J., Diamond-like carbon thin film. Material science and Engineering, 37 (2002) pp.129-281.

[10] Q. Wei, R.J.N., A. K. Sharma, J. Sankar, and J. Narayan, Preparation and mechanical properties of composite diamond-like carbon thin films. Vacuum, Surfaces, and Films, 6. (1999).

DOI: 10.1116/1.582074

[11] Md. Kamrul Hassan, B.K.P. a.A.H., Electrical Resitivities of the Diamod-Like carbon Films Fabricated from Methane and Acetylene Using RF Plasma. New diamond and Frontier Carbon Technology, 16. (2006) pp.211-219.

[12] Kruzelecky, R.V., Zukotynski, S., DC saddle-field plasma-enhanced vapour depostion, in Plasma Properties Deposition and Etching. Materials Science, 140-142 (1993) pp.89-106.

DOI: 10.4028/www.scientific.net/msf.140-142.89

[13] Pletnev, V., Zukotynski, S., Energy spectra of electrons in a dc glow charge with a semitransparent anode. J. Vac. Sci. & Technol. A, 19(2) (2001) pp.591-598.

DOI: 10.1116/1.1349200

[14] M. Koos, M.F., M. Veres, S. Toth, I. Pocsik Multi-band structure of amorphous carbon luminescene. Diamond and Related Materials, 11 (2002) pp.1115-1118.

DOI: 10.1016/s0925-9635(01)00713-0

[15] Fang, R. c., Emission properties of amorphous silicon and carbon films. Journal of Luminescene, 48 & 49 (1991) pp.631-635.

[16] Schrader, B., Infared and Raman Spectroscopy, Method and application, 41(1) (1995) p.98.

[17] B. Dischler, A.B., P. Koidl, Hard carbon coatings with low optical absorption. Journal of Applied Physics Letter, 42(8) (1983) pp.636-638.

DOI: 10.1063/1.94056

[18] B. Dischler, P.K., P. Oelhafen, Amorphous hydrogenated carbon films, 17(1987) p.187.
