The Transmission Spectrum of Symmetrical Structured One-Dimensional Photonic Crystals of Positive and Negative Materials

Abstract:

The transmission spectrum of symmetrically structured one-dimensional photonic crystal (AB)_m(BA)_m consisting of positive and negative materials was studied with transfer matrix method theory. The result shows that a single narrow transmission peak constantly appears at the frequency of uneven ω/ω₀, while a broad transmission peak appears at the frequency of even ω/ω₀. When periodicity m or refractive index n_A of Layer A increase, the narrow transmission peaks in the spectrum become sharper and the broad peaks become narrower; as refractive index n_B of Layer B rises, all the peaks in the spectrum become broader; and when the thickness d_A of Layer A medium thicken, the transmitting peaks move towards alto frequency,while with the thickening of d_B of Layer B medium, these peaks move inversely towards low frequency. Furthermore, in these two circumstances, the transmitting peaks at right alto frequency move faster; however, peaks remain unchanged when both d_A and d_B concurrently thicken. All these optical transmission characteristics of symmetrically structured one-dimensional photonic crystals can offer guidance to designing adjustable super-narrow optical filters, broad band filters and optical switches.

• Periodical: Advanced Materials Research (Volume 904)
• Pages: 67-70
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.904.67
• Online since: March 2014
• Authors: An Su*
• Keywords: Double Negative Material (DNM), Filter, Photonic Crystal (PC), Transmission Spectrum

References

[1] Yablonovitch E. Inhibited spontaneous emission in solid-state physics and electronics [J]. Phys Rev-Lett, 1987, 58(20): 2059~(2061).

DOI: 10.1103/physrevlett.58.2059

[2] John S. Strong localization of photons in certain disordered dielectric superlattices[J]. Phys RevLett, 1987, 58(23): 22486~2489.

DOI: 10.1103/physrevlett.58.2486

[3] Su An, Gao Ying-jun. Filter characteristics of one-dimensional photonic crystal with complex dielectric constant [J]. Chinese Journal of Lasers, 2009, 36(6): 1535-1538(Ch).

[4] Su An. Transmission spectrum of one-dimensional photonic crystal for realizing high-performance optical transmission function [J]. Infrared and Laser Engineering, 2011, 40(6): 1101-1106 (Ch).

[5] Su An, Gao Yingjun. One dimensional Photonic Crystal Quantum well Structure Containing Complex Dielectric Constant [J]. Acta Photonica Sinica, 2010, 39 (5): 842-846 ( Ch).

DOI: 10.3788/gzxb20103905.0842

[6] Su An, Zhang Ning. Transmission Spectrum Characteristics of Single-negative Materials with One-dimensional Photonic Crystal [J]. Chinese Journal of Luminesence, 2010, 31(3): 439-444 (Ch).

[7] Veselago V G. Theelectrod ynamics of substances with simultaneously negativevalues of ε and μ[J]. Sov. Phys. Usp., 1968, 10 (4) : 509~514.

DOI: 10.1070/pu1968v010n04abeh003699

[8] Dong Haixia, Jiang Haitao, Yang Chengquan et al. Theoretical simulation and transmission properties of 1-D photonic QW structure containing defect layers with negative refractive index [J]. Acta Optica Sinica, 2007, 27(12): 2245-2249 (Ch).
