Experimental Study of Impact Strength of Al-6063 Alloy Processed by Equal Channel Angular Extrusion

Abstract:

In the present study, the impact strength of annealed Al-6063 alloy developed by equal channel angular extrusion (ECAE), up to 6 passes at a temperature of 200^°C following route A with a constant ram speed of 30 mm/min through a die angle of 90^° between the die channels was investigated. The impact strength of extruded specimens is evaluated for different passes at a strain rate of 1800 s^-1using Split-Hopkinson pressure bar techniques. The results indicate that the major strength improvement occurs in the 5^th and 6^th passes while in primary passes, the strength improved but at a considerably lower rate. A total increasing in ultimate strength (UTS) and yield strength (YS) are 127% and 65% respectively and observed for the extruded material after 6 passes. Optical microscopic examinations show a grain refinement from 45 μm to 2.8 μm.

You might also be interested in these eBooks

Key Engineering Materials - Development and Application

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 911)

Pages:

158-162

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.911.158

Citation:

Cite this paper

Online since:

March 2014

Authors:

Sreenivasan Sulaiman*, J. Nemati, Hani Mizhir Magid, B.T.H.T. Baharudin, G.H. Majzoobi, M.A. Azmah Hanim

Keywords:

Al-6063, Equal Channel Angular Extrusion (ECAE), Grain Refinement, Impact Strength, Split-Hopkinson Pressure Bar

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J.K. Kim, D.Y. Yang, J.W. Yoon: Mater. Sci. and Eng A Vol. 527 (2010), p.7927.

Google Scholar

[2] A. Rebhi, T. Makhlouf, N. Njah, Y. Champion J.P. Couzinié: Mater. Characterization Vol. 60 (2009), p.1489.

DOI: 10.1016/j.matchar.2009.08.004

Google Scholar

[3] S. Dadbakhsh, A. Karimi Taheri, C.W. Smith: Mater. Sci. and Eng A Vol. 527 (2010), p.4758.

Google Scholar

[4] Akhtar S. Khan and Christopher S. Meredith: Int.J. Of Plasticity Vol. 26 (2010), p.189.

Google Scholar

[5] Ehab A. El-Danaf: Mater. And Design Vol. 32 (2011), p.3838.

Google Scholar

[6] K.R. Cardoso, D.N. Travessa, W.J. Botta, A.M. Jorge Jr.: Mater. Sci. and Eng A Vol. 528 (2011), p.5804.

Google Scholar

[7] P.L. Sun, E.K. Cerreta, G.T. Gray III, J.F. Bingert: Metall. and Mater. Trans. A Vol. 37 A (2006), p.2983.

Google Scholar

[8] U. Chinta Babu, Kartik Prasad and S.V. Kamat: Trans. of the Indian Institute of Metals Vol. 64 (2011), p.321.

Google Scholar

[9] A. Mishra, M. Martin, N.N. Thadhani, B.K. Kad, E.A. Kenik, M.A. Meyers: Acta Materialia Vol. 56 (2008), p.2770.

DOI: 10.1016/j.actamat.2008.02.023

Google Scholar
