Numerical Simulation for the Effects of Ice Thickness on the Overhead Transmission Cable Tension

Abstract:

A model of single span overhead transmission cable was established in this paper, based on nonlinear finite element theory, combined with supports displacement method and node equilibrium method, form-finding analysis was carried out for the model of single span overhead transmission cable, the cable tension of model was compared with the theoretical calculation value, and the correctness of the model was verified. Then update cable model was analyzed, the sag, tension and ends tilt of cable under different ice thickness was discussed. This paper provided a reliable method for on-line monitoring the safety of overhead transmission cable in icing conditions.

• Periodical: Advanced Materials Research (Volumes 919-921)
• Pages: 1307-1311
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.919-921.1307
• Online since: April 2014
• Authors: Zha Wang, Ji Yao*, Sun Peng
• Keywords: Form-Finding Analysis, Geometric Nonlinear Finite Element, Overhead Transmission Cable

References

[1] X. F. Zeng: The initial shape of the cable structure determination and optimization studies, Southeast University, Nanjing (2004).

[2] F. Wang, Y. H. Zhang: Shanxi Arch Vol. 33 (2007), p.76.

[3] T. X. Song: Nonlinear finite element structure, Huazhong University Press, Wuhan (1996).

[4] S. Z. Shen, C. H. Xu, C. Zhao: Cable structure design, China Building Industry Press, Beijing (1997).

[5] T. X. Shao: Overhead transmission line wire mechanics calculations, China Cable Press, Beijing (2003).
