Heat Transfer Enhancement of Impinging Jet from Pulse Jet Combustor

Abstract:

The aims of this study are to investigate flow characteristics in pulse jet combustor and heat transfer characteristics of impinging jet from pulse jet combustor. The combustor is Helmholtz type which has single combustor chamber and single tailpipe. The inner diameter (D) of tailpipe was 47 mm and tailpipe length was about 16D. The effect of number of air inlets: single inlet, double inlets with 90^o apart, double inlets with 180^o apart and triple inlets with 90^o apart on flow and heat transfer characteristics were studied. A water cooled heat flux sensor was applied to measure heat transfer rate on the surface at stagnation point. The jet-to-plate distance was varied at L=1D, 2D, 4D, 6D and 8D. Two of pressure transducers were mounted on the wall of combustion chamber and on the wall of tailpipe at 4D from tailpipe outlet to measure pressure simultaneously. It is found that the variation of pressure near the tailpipe outlet is strongly depended on air inlet configurations. The pressure variations in pulse jet combustor could be preliminary related to the temperature and velocity of jet from tailpipe and heat transfer rate on jet impingement surface.

• Periodical: Advanced Materials Research (Volumes 931-932)
• Pages: 1228-1232
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.931-932.1228
• Online since: May 2014
• Authors: Pathomporn Narato, Kittinan Maliwan, Chayut Nuntadusit*
• Keywords: Air Inlet Configurations, Flow Characteristic, Heat Transfer Characteristic, Impinging Jet, Pulse Jet Combustion

References

[1] Giammer RD, Putnam AA. Noise reduction using paired pulse combustion. J Energy 1978; 2(5): 319–20.

[2] Putnam AA, Belles FE, Kentfield JAC. Pulse combustion. Prog Energy Combust Sci 1986; 12: 43–79.

DOI: 10.1016/0360-1285(86)90013-4

[3] Zinn BT. Pulse combustion: recent applications and research issues. In: Twenty-fourth symposium (international) on combustion/the combustion institute; 1992. p.1297–305.

DOI: 10.1016/s0082-0784(06)80151-7

[4] Geng, T.; Zheng, F.; Kiker, A.P.; Kuznetsov, A.V.; Roberts, W.L. Experimental and numerical investigation of an 8-cm valveless pulsejet. Experimental Thermal and Fluid Science 31(2007) 641-647.

DOI: 10.1016/j.expthermflusci.2006.06.005

[5] Kilicarslan, A.; Arisoy,A. Acoustic analysis of a liquefied petroleum gas-fired pulse combustor. Applied Acoustics 69(2008) 770-777.

DOI: 10.1016/j.apacoust.2007.05.003

[6] Kudra,T.; Mujumdar A.S. Pulse combustion drying , In Advance Drying Technologies, 2 nd Edition, Taylor & Francis, PP. 225-261.

[7] Geng,T.; Schoen M.A.; Kuznetsov A.V.; Roberts W.L. Combined Numerical and Experimental Investigation of a 15-cm Valveless Pulsejet. Flow Turbulence combust 78 (2007) 17-33.

DOI: 10.1007/s10494-006-9032-8

[8] Waitz I.A.; Gauba,G., Tzeng,Y.: Combustors for micro-gas turbine engines.J. Fluids Eng. 120, 109-117 (1998).

DOI: 10.1115/1.2819633

[9] Spadaccini C.M., Mehra,A., Lee,J., Zhang,X., Lukachko,S., Waitz I.A.: High power density silicon combustion systems for micro gas turbine engines.J. Eng. Gas Turbines Power 125, 709-719(2003).

DOI: 10.1115/1.1586312
