Adaptive Planning Method for Measuring Points of Blade Section Line

Abstract:

An adaptive planning method for measuring points of blade section line is presented due to the less distribution of measuring points along the blade edge specified by chordal tolerance method which results in the edge information loss. Based on the chordal tolerance method, the adaptive planning method provides the number and distribution of measuring points along the blade section line on condition of the given initial number of measuring points and threshold value of chordal tolerance. A simulation system based on MATLAB is developed to compare the adaptive planning method with the chordal tolerance method. The measuring tests of blades are carried out according to the measuring points specified by chordal tolerance method and by adaptive planning method respectively. The simulation and measuring results indicate that the distribution of measuring points along the blade edge specified by adaptive planning method is more reasonable than those by chordal tolerance method and that the total number of measuring points is reduced considerably and the measuring efficiency is increased by adaptive planning method.

• Periodical: Advanced Materials Research (Volume 940)
• Pages: 503-508
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.940.503
• Online since: June 2014
• Authors: Lei Zhang*, Xiao Dan Tan, Qiang Yuan, Shi Jun Ji
• Keywords: Adaptive Planning Method, Blade, Chordal Tolerance Method, Measuring Points

References

[1] P. Xi, X. Sun, Error analysis system of turbine blade based on CAD model, Journal of Beijing University of Aeronautics and Astronautics 34 (2008) 1159-1162.

[2] Y. Li, C. Huang, Y. Lu, et al, CAD-based inspection of free-form surfaces, Journal of Sichuan University (Engineering Science Edition) 36 (2004) 90-93.

[3] Y. Ding, Y Li, Y. Cui, Automatic generation of on-line inspection measuring points based on curvature change matrix for aircraft structural parts, Mechanical Science and Technology 29 (2010) 778-782.

[4] B. Li, Z. Sun, F. Peng, et al, Research on on-line probing measure-point layout for blade parts, China Mechanical Engineering 19 (2008) 540-546.

[5] S. Z. Li, Adaptive sampling and mesh generation, Computer-Aided Design 27 (1995) 235-240.

DOI: 10.1016/0010-4485(95)95872-c

[6] T. H. Hsu, J. Y. Lai, W. D. Ueng, On the development of airfoil section inspection, International Journal of Advanced Manufacturing Technology 30 (2006) 129-140.

DOI: 10.1007/s00170-005-0046-5

[7] K. Mohaghegh, M. H. Sadeghi, A. Abdullah, Reverse engineering of turbine blades based on design intent, International Journal of Advanced Manufacturing Technology 32 (2007) 1009-1020.

DOI: 10.1007/s00170-006-0406-9

[8] L. Zhao, H. Yang, R. Mo, et al, Research on tool path planning for NC machining and measurement technology of a blade surface, Science Technology and Engineering 11 (2011) 2691-2696.

[9] F. Z. Shi, Computer-aided Geometric Design and Non-uniform Rational B-spline, Higher Education Press, Beijing, (2001).

[10] L. Piegl, W. Tiller, Non-uniform Rational B-spline, 2nd ed., Tsinghua University Press, Beijing, (2010).
