The Design and Development of Fully Automatic Ultrasonic Hot Rig

Abstract:

There are something wrong with traditional hot rig.Such as poor efficiency,low precision,exploding diamond easily,rickety hotting diamond and so on.Introduced operational principle of mechanism,electronical control of ultrasonic and pneumatic principle.The machine use only one stepper motor to realized inhaling diamond linkage’s swinging and location,and then the structure is simple and reliable.
