Development on Experimental System of Kinematic Performance of 3-TPS Hybrid Robot

Abstract:

Hybrid robot combines the advantages of serial and parallel structure and has the characteristics of large workspace, agile kinesis, good stiffness, compact structure, good kinematic performance and so on. To conduct the research on the performance of hybrid robot, this dissertation develop an experimental system based on the new 3-TPS hybrid robot which is develop by the research institute of advance manufacturing technology and automation in Northeast University to drive the robot and examine the operational position, and it is also applied in the demarcate experimental of 3-TPS hybrid robot. Through the application, it draws a conclusion that the experimental system has the characteristics of simple structure, good function, good compliance, simply to operate, high reliability and low cost. Consequently, it has high value of popularization and application to conduct the experiment and research on hybrid robot.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1380-1383
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1380
• Online since: June 2014
• Authors: Jia Shun Shi, Kai Wang, Li Da Zhu*, Wan Shan Wang, Jian Yu Yang
• Keywords: Configuration Software, Encoder, Hybrid Robot, Motion Control

References

[1] Y. Liu, T. Cheng, L. Zuo and C. Wang. Development of an Open Parallel Intelligent CNC Milling System Part 2. Milling Experiment [J]. Advanced Manufacturing Technology 2000, 16: 542–546.

DOI: 10.1007/s001700070042

[2] Zhu Lida, Shi Jiashun, Cai Guangqi, Wang Wanshan. Emulation of kinematics and dynamics of 3-TPS hybrid robot based on ADAMS[J]，Journal of Northeast University ，2007. (10): 34-37.

[3] S. Bellakehal, N. Andreff, Y. Mezouar, M. Tadjine Vision/force control of parallel robots[J]. Mechanism and Machine Theory 2011, 46：1376–1395.

DOI: 10.1016/j.mechmachtheory.2011.05.010

[4] Takuma Uchiyama1, Hidetsugu Terada1, Hironori Mitsuya. Continuous path control of a 5-DOF parallel-serial hybrid robot [J], Journal of Mechanical Science and Technology, 2010, 24: 47~50.

DOI: 10.1007/s12206-009-1166-x

[5] Miguel Diaz-Rodriguez, Angel Valera, Vicente Mata, and Marina Valles. Model-based control of a 3-DOF parallel robot based on identified relevant parameters [C], IEEE/ASME Transactions on Mechatronics, 2012: 1-8.

DOI: 10.1109/tmech.2012.2212716

[6] Z.M. Bi, Development and Control of a 5-Axis Reconfigurable Machine Tool [J]. Journal of Robotics, 2011, 9: 20-29.

[7] David Corbel，Olivier Company, Sebastian Krut，François Pierrot Enhancing PKM Accuracy by Separating Actuation and Measurement: A 3DOF Case Study[J]，Journal of Mechanisms and Robotics, 2010, 2(3): 11-32.

DOI: 10.1115/1.4001779

[8] Li Bin, Huang Tian, Liu Haitao, Zhao Xinhua. Position Analysis of a 3- DOF PKM Module for a 5- DOF Hybrid Robot Exechon [J]. China Mechanical Engineering，2010, 21(23): 2785-2789.

[9] Khalil, W. el, Besnard.S. Self calibration of Stewart-Gough parallel robot without extra sensors [J]. IEEE Transactions on Robotics and Automation，1999（12），15（6）：1116~11.

DOI: 10.1109/70.817674
