Capturing Energy-Saving Opportunities in Air-Supply System for Cleanroom with Non-Unidirectional Airflow

Abstract:

In order to improve design method and optimize control strategy used in non-unidirectional airflow cleanroom, the influence of airflow organization and supply air volume on characterization of mini-environments in a non-unidirectional cleanroom was studied in the paper. A series of investigations were conducted on a cleanroom experimental platform with different airflow organization modes and supply air volume variation by electronic frequency conversion (35 to50Hz, 5Hz interval) on air-supply fan unit. The characterization such as cleanliness , pressure difference between clean zone and outdoor were measured during these experiments. It is shown that radiation air-supply airflow organization can offer higher cleanliness when compared with traditional ceiling-supply and wall-return airflow for non-unidirectional airflow cleanroom without increase power consumption. Taking variable electronic frequency on air-supply fan unit is efficient measure for energy-saving in cleanroom operation.

• Periodical: Advanced Materials Research (Volumes 953-954)
• Pages: 1488-1491
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.953-954.1488
• Online since: June 2014
• Authors: Yu Wang
• Keywords: Air-Supply System, Cleanroom, Energy Saving, Non-Unidirectional Airflow

References

[1] Tengfang Xu. Characterization of minienvironments in a cleanroom: assessing energy performance and its implications. Building and Environment. 2008(43), 1545-1552.

DOI: 10.1016/j.buildenv.2007.09.003

[2] Ti Lin, Yun-Chun Tung, Shih-Cheng Hu, Chen-Yen Lin. Effects of the removal of 0. 1μm particles in industrial cleanroom with fan dry coil unit return system. Aerosol and air quality research. 2010(10), 571-580.

DOI: 10.4209/aaqr.2010.03.0014

[3] Shiguang Hu, Xiaosheng Li and Yanxiang Ma. Variable frequency energy saving reformation for air handing units in a clean room, Journal of HV&AC (in Chinese), 2013, 43(3), 71–73.

[4] Houmeng Zhao. The probe on operation control to clean air conditioning, Contamination control & air-conditioning technology (in Chinese), 2013, 1, 77–79.

[5] Jinliang Zhao, Junjie Liu and Neng Zhu. Optimization of Airflow in High Cleanliness Level cleanroom, Fluid machinery (in Chinese), 2005, 33(4), 59–62.

[6] Code for design of clean room (in Chinese), GB 50073-2001, 35-40.

[7] Code of acceptance for construction quality of ventilation and air conditioning works (in Chinese), GB 50243-2002, 94-97.
