Study of Vehicle Power Supply with AC and DC Mixed Output

Abstract:

The paper proposes a AC and DC mixed output VPS(vehicle power supply). It is composed of a two-stage circuit with the input stage and the output stage. The input stage contains a single-phase PWM inverter, a HFT (high-frequency transformer) and an uncontrolled rectifier. The single-phase PWM inverter adopts the open-loop control strategy to convert the low DC voltage into a high-frequency one with square wave. The HFT enhances the voltage and insulates the low-voltage side from the high-voltage side. The uncontrolled rectifier transforms the square voltage into DC voltage. In the output stage, one output uses single-phase PWM inverter and the other uses a DC chopper, both of which adopt the double-loop PWM control mode. The mode consists of an outer voltage loop and an inner current loop to produce desirable voltage and power. With the two-stage control strategy, ideal output currents and the output voltages are obtained, and the input power factor is controllable. The VPS model is established on MATLAB/SIMULINK, and this system is also implemented in laboratory based on DSP TMS320F28335. The results of simulation and experiment verify the proposed VPS system.

• Periodical: Advanced Materials Research (Volumes 960-961)
• Pages: 1225-1229
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.960-961.1225
• Online since: June 2014
• Authors: Xing Wu Yang*, Hong Chao Ji, Wei Gan
• Keywords: AC, DC Mixed Output, Double-Loop PWM Control, Vehicle Power Supply

References

[1] Huang Yi-yu, Mao Cheng-xiong, Lu Ji-ming, Fan Shu. Study on control strategy for power electronic transformer in power system. Relay, 2004, 32(6): 35-39.

[2] Mao Cheng-xiong, Fan shu, Wang Dan. Theory of Power Electronic Transformer and Its Applications. High Voltage Engineering, 2003, 29(10): 4-6.

[3] Deng Wei-hua, Zhang Bo, Hu Zong-bo. Research on the topology and control scheme of power electronic transformer. Automation of Electric Power System, 2003, 27(20): 40-44, 48.

[4] Cheng Jian-peng, Mao Cheng-xiong, Fanshu. Principle of electronic power transformer and its simulation study. Electric Power Automation Equipment, 2004 , 12(24): 23-26.

[5] Cui Yan-yan, Mao Cheng-xiong. Voltage and reactive power synthetic optimization in the distribution system based on electronic power transformer. Relay, 2006, 34(6): 24-28, 43.

[6] Wang Dan, Mao Cheng-xiong, Lu Ji ming, Fan Shu. Electronic Power Transformer-Based Power Quality Control Method. High Voltage Engineering, 2005, 31(8): 63-65, 82.

[7] Wang Dan, Mao Cheng-xiong, Lu Ji-ming, Fan Shu, Cao Jie-wei. Simulation research on imbalance loads of electronic power transformer in distribution system. Electric Power, 2005, 38(11): 21-26.

[8] Shi Sai-mei. Dynamic simulation of power electronic transformer in parallel operation. Power System Protection and Control, 2009, 2(17): 20-23.
