Investigation on Type-4 and Type-11 Mixed Topology of LLC Resonant Converter

Abstract:

LLC resonant converter can adjust the output for a wide range of source and load with a small fluctuation of switching frequency, so it is used widely. This paper introduces all arrangements of LLC topological group, then proposes a new topology which is consist of Type-4 and Type-11 that used widely,in this paper we also give its calculate method of resonant frequency. Lastly we get gain characteristics of the topologies in the PSpice simulation environment and analyse the influence factors on adjustment ability in certain load range .
