Experimental Tests for the Analysis of the Load-Bearing Capacity of an Internal Slab-Column Connection after its Punching at Various Positions of the Column

Abstract:

Normally, in practice the situation of a slab-column structure is rarely analyzed after the occurrence of a local breakdown. Catastrophes which have happened so far indicate the need of considering in detail slab-column connections in reinforced concrete structures in order to prevent progressive collapses. Some suggestions concerning the prevention of such situations are to be found merely in CSA A23.3-04 and ACI 318. This problem is not dealt with in the Polish Standards, nor in the Eurocodes. The paper presents the results of investigations performed on a model of slab-column connections in the scale 1:1. Three variants of the position of the column in relation to the centre of the slab have been considered: the axial position, the position in an unidirectional eccentricity, and in bidirectional eccentricity. The tests were performed in two phases, viz. "Phase 1" preceding the punching and "Phase II" after punching to the complete destruction of the connection. The aim of these investigations was to find out how far any additional bending moment resulting from the eccentric effect of the load affects the value of the destructive load imposed on the connection after its punching. The obtained results permitted to determine the relations between the exerted load and the displacement of the column in time, and also to determine the values of the force at which the rupture of the bars above the column had taken place. The results of these tests were compared with the standard.

• Periodical: Advanced Materials Research (Volume 969)
• Pages: 169-175
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.969.169
• Online since: June 2014
• Authors: Barbara Wieczorek*
• Keywords: Experimental Research, Progressive Collapse, Punching, Reinforced Concrete Structure, Slab-Column Connections, Two-Way Slabs Structural Integrity Reinforcement

References

[1] ACI Committee 318, Building code requirements for structural concrete and commentary, American Concrete Institute, United State America, (2011).

[2] CSA Standard A23. 3-04, Design of concrete structures, Canadian Standard Association, (2004).

[3] PN-EN 1992-1-1: 2004/AC, Eurocode 2, Design of concrete structures - Part 1-1: General rules and rules for buildings, European Standard, (2010).

DOI: 10.3403/03178016

[4] N.M. Hawkins, D. Mitchell, Progressive collapse of flat plate structures. Journal of the American Concrete Institute, 76(7), (1979).

[5] G. Melo, P. Regan, Post-punching resistance of connections between flat slabs and interior columns, Magazine of Concrete Research, 50(4), (1998).

DOI: 10.1680/macr.1998.50.4.319

[6] Y. Mirzaei, Post-punching behavior of reinforced concrete slabs. Ph.D. thesis, School of Architecture, Civil and Environmental Engineering, Ecole polytechnique fédérale de Lausanne (EPFL), Switzerland, (2010).

DOI: 10.3940/rina.innovsail.2010.14

[7] J. Sagaseta, A. Muttoni, M. Fernandez Ruiz, L. Tassinari, Non-axis-symmetrical punching shear around internal columns of RC slabs without transverse reinforcement. Magazine of Concrete Research, Paper 1000098, UK, (2011).

DOI: 10.1680/macr.10.00098

[8] B. Wieczorek, Influence of the location of the column on the load capacity of a slab-column connection for the inner column after punching, Procedia Engineering, Vol. 57, (2013).

DOI: 10.1016/j.proeng.2013.04.158

[9] B. Wieczorek, Idea of a simplified model to determination of the load capacity of and inner slab-column connection after its punching, Procedia Engineering, Vol. 65, (2013).

DOI: 10.1016/j.proeng.2013.09.022

[10] B. Wieczorek, Load-bearing capacity of reinforcing bars in the zone of the slab-column connection determined experimentally and in the result of numerical calculations, Procedia Engineering, Vol. 65, (2013).

DOI: 10.1016/j.proeng.2013.09.025

[11] M. Wieczorek, Influence of amount and arrangement of reinforcement on the mechanism of destruction of the corner part of a slab-column structure, Procedia Engineering, Vol. 57, (2013).

DOI: 10.1016/j.proeng.2013.04.159

[12] M. Wieczorek, Investigations concerning the corner part of the reinforced concrete structure in the emergency of removing the corner support, Procedia Engineering, Vol. 65, (2013).

DOI: 10.1016/j.proeng.2013.09.023

[13] M. Wieczorek, Concept of shell-beam model of slab-column connection based on analysis of the 3D model, Procedia Engineering, Vol. 65, (2013).

DOI: 10.1016/j.proeng.2013.09.026
