The Research of Structural Optimization on Diesel Engine Injection Nozzle

Abstract:

In order to improve the performance of 16 V280 diesel engine, the three-dimensional numerical models of the flow field in the nozzle which belongs to the injection system was built, and different detailed flow structures was captured under different pressure conditions. Through the analysis of the flow field, the unsuitable position of the nozzle was located, and the methods which combine CAD / CAM / CFD was applicated to optimize the structure of the nozzle. The analysis results indicate that with the increase of the injection pressure; the flow turbulence intensity increases; the more energy get lost, which was caused by turbulence; the coefficient of flow decreases. After the spray nozzle structure was changed into sphere pin valve, the mass flux under the same level of injection pressure was improved greatly.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 2571-2575
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.2571
• Online since: March 2010
• Authors: Ming Hai Li, Hong Jiang Cui, Yun Dong Han, Ang Li
• Keywords: Diesel Engine, Injection Nozzle, Numerical Simulation, Optimization

References

[1] Li Minghai, Liu Jianwei, Wang Qian. Internal combustion engine, 2006(1): pp.48-50 (In Chinese).

[2] He Zhixia, Yuan Jianping, Li Detao and others. Internal combustion engine journal, 2006 (1) pp.35-41 (In Chinese).

[3] Xu Bo, Zhang Zongjie, Qi Maoguo. The modern vehicle uses the power, 2005(1): pp.17-21.

[4] Zhang Jinyang, Wang Junxiao, Lu Jiaxiang. Shandong Internal Combustion Engine, 2003 (1).

[5] Wang Fujun. Computational fluid dynamics analysis. Beijing: Qinghua University publishing house, (2004).

[6] Matsouka S, Yokota K, etal. A Study of Fuel Injection System in Diesel Engines, Parts I&II, SAE Paper 760551, 760552.

[7] Fluent Inc. FLUENT User Defined Function Manual Fluent Inc. (2003).
