The Drum Height Detection Model of the Shearer Cutting Memory Program Control

Abstract:

The drum height was detected reliably, one of the main parameters for requirements of the shearer cutting memory program control was obtained. According to the principle of the drum lifting mechanism, two kinds of sensor detection conversion mathematical model based on the rocker angular displacement and the lifting cylinder linear displacement were established, the mathematical relation between the drum height and the sensor detection quantity and precision was derived, and the error of two kinds of detection was comparatively analyzed, therefore the theory basis to choose the sensor tape and precision to shearer cutting memory program control is provided.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 2690-2694
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.2690
• Online since: March 2010
• Authors: Yue Hua Sun, Chun Sheng Liu, Xiao Ming Liang, Xiao Lin Yan
• Keywords: Detection Precision, Drum Height, Mathematical Models, Shearer

References

[1] Liu Chun-sheng. The mining of mechanical and electrical, 2004(5), p.22.

[2] Liu chun-sheng, Jing Kai Journal of China Mechanical Engineering Vol. 5(2)(2007), p.142.

[3] ORTEA J J, CATALINA J C, DEVY M. International conference on Robotics and Automation, France , 1992(5), p.626.

[4] Xiang Yang, Chen Nan, Hu Yingxi. The mining of mechanical and electrical, 2001(3), p.4.

[5] Xiang Yang, Hu Yingxi. Journal of Guizhou University of Technology (Natural Science Edition), Vol. 28(5)(1999).
