A 3D Modeling System for Construction Work Simulation Based on Rendering and Dynamic Engines

Abstract:

Modeling System for Construction task Simulation (MSCS) presented in this paper is a 3D computer-aided drawing tool which is designed for construction task planners. It is based on OGRE (Object-oriented Graphics Rendering Engine) and Bullet Dynamic Engine, therefore the model created by MSCS has both geometric and dynamic properties. MSCS has already been used in Crawler Crane’s Lifting Simulation System which is developed by Dalian University of Technology in China to draw the work environment and the loads to be lifted.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 3455-3458
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.3455
• Online since: March 2010
• Authors: Xin Wang, Jing Zhang, Shun De Gao, Di Wu
• Keywords: 3D CAD, Cnstruction Work, Modeling, Open Source Engine

References

[1] R. Kamat, and C. Martinez: submitted to Journal of Computing in Civil Engineering Vol. 15 (2001), pp.329-337.

[2] R. Kamat, and C. Martinez: submitted to Journal of Computing in Civil Engineering Vol. 19 (2005), pp.356-368.

[3] J. Gregory: Pro OGRE 3D Programming (Apress Press 2006).

[4] Information on http: /www. bulletphysics. com/wordpress.

[5] J. Lien, and M. Amato: submitted to Proceedings of the 2007 ACM symposium on Solid and physical modeling (2007), pp.121-131.

[6] J. Xu: submitted to IEEE Transactions on Pattern Analysis and Machine Intelligence, Vol. 13 (1991), pp.153-162.

[7] M. R. O. Axel Seugling: Dissertation, Umea University. (2006).
