Structure Design and Multi-Domain Modeling for a Picking Banana Manipulator

Abstract:

Based on agronomic and harvest characteristic analysis for bananas, according to bionic principle, a mechanism of picking banana manipulator simulating action of a person manually picking bananas was proposed, which was consisted of rotary mechanism, lifting mechanism, and shift mechanism, the body mechanical model of the picking banana manipulator was established. The multi-domain uniform model of a picking banana manipulator was developed employing the virtual simulation and modeling language Modelica. A body structure model for picking banana manipulator was established based on component models in DriveLib model library. Motion control’s mathematic models for picking banana manipulator were analyzed according to drive motor performance for the body structure, the simulation model of a mechanical motion control for the picking banana manipulator were realized in Dymola simulation platform. The validity models could provide a theoretical basis for picking banana manipulator primary design.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 3560-3564
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.3560
• Online since: March 2010
• Authors: Hong Jun Wang, Jia Xin Chen, Xiang Jun Zou, Chang Yu Liu
• Keywords: Modelica, Multi-Domain Simulation, Picking Manipulator, Structure Design

References

[1] Sario Y: Journal of Agricultural Engineering Research, Vol. 54 (1993), p.265.

[2] G. Markus, B.S. Thomas: Journal of Automatic, Vol. 43 (2007), p.416.

[3] S.M. Pedersen, S. Fountas, H. Have: Journal of Precision Agric. Vol. 7 (2006), p.295.

[4] T.S. Yao, W.M. Ding: Transactions of the CSAE, Vol. 22 (2006), p.250.

[5] J.Z. Liu, P.P. Li, Z.G. Li: Transactions of the CSAE, Vol. 24 (2008), p.66.

[6] X.J. Zou, S. Jin, Y. Chen, J. Lu, H.J. Wang: Journal of System Simulation. Vol. 21 (2009), p.5882.

[7] W.H. Ou: Thesis, South China Agricultural University, Mar. (2009).
