Design and Theoretical Analysis of Mini-Plunger Sprayer Used in SW2502 Fused Deposition Modeling System

Abstract:

The fused deposition modeling rapid prototyping system is based on the manufacturing principle of layer by layer. The sprayer is the key component which achieves the fused deposition process. Based on the polymer rheological property, the structure design and theoretical analysis of the mini-plunger sprayer of SW2502 fused deposition modeling system are studied. The plasticizing capacity of the mini-plunger sprayer is analyzed in theoretically. It’s very important for the fused deposition modeling process to maintain a stable plasticizing capacity. The driving force of ABS feed is related to several process parameters such as structure form of sprayer and material property, etc. The barrel and nozzle design should be fit for mobility, purity and mechanical property of ABS feed. The modified ABS feed adopts self-pressure-adding driving method to conquer the pressure losses of barrel and nozzle. The plasticizing capacity of the sprayer is more than 20g/h.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 4010-4015
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.4010
• Online since: March 2010
• Authors: Bin Liu, Man Hua Peng, Yan Hong Feng, Fu Zhen Wang
• Keywords: Fused Deposition Modeling (FDM), Micro Extrusion, Mini-Plunger Sprayer, Rapid Prototyping (RP)

References

[1] Yongnian Yan, Renji Zhang, Qingping Lu, etc: The Third International Conference on Rapid Prototyping and Manufacturing (2001). [In Chinese].

[2] Xue Yan, P Gu: Computer-Aided Design, Vol. 28 (1996), pp.307-318.

[3] J. P. Kruth, M. C. Leu and T. Nakagawa: Annals of CIRP, Vol. 47(1998), pp.525-540.

[4] Yungan Wang: Rapid Prototyping Technology (Huazhong University of Science and Technology Press, China 1999). [In Chinese].

[5] Xingtian Wang: Injection Molding Technology (Chemical Industry Press, China 1998). [In Chinese].

[6] Kong Gairong: Beijing University of Chemical Technology (1999). [In Chinese].

[7] S. S. Crump and M. Minn, U.S. Patent 5, 340, 433. (1994).

[8] Yongnian Yan, Shengjie Li, Renji Zhang, etc: Tsinghua Science & Technology, Vol. 14 (2009), pp.1-12.

[9] Dongsheng Yan, Zhiqing Cao and Gairong Kong: Journal of Beijing University of Chemical Technology, Vol. 30 (2003), pp.71-73. [In Chinese].

[10] Lisong Zhu, Chunsheng Ye and Shuhuai Huang: Machine Tool & Hydraulics, Vol. 1 (2005), pp.28-29. [In Chinese].
