Surface Plasma Characterization of Polyimide Films for Flexible Electronics

Abstract:

Flexible electronics have drawn much attention due to vast application possibilities. Polyimide was the substrate of choice as a flexible substrate owing to its properties such as good mechanical strength, high temperature resistance, good dimensional stability, and low dielectric constant. The adhesion between metal and polymer substrate plays a crucial role for reliability of these applications and low adhesion was the cause for most failures. In this study, plasma surface treatments were applied on polyimide surface by inductively coupled plasma (ICP) treatment system. The results of contact angle measurements and atomic force microscopy (AFM) show a large increase in surface roughness with increasing treatment time. Complete wetting was found for both argon and oxygen plasma treatment. Analysis of chemical composition by FTIR reveals an increase in carbon-oxygen functional groups and the concentration of oxygen on the surfaces.

• Periodical: Advanced Materials Research (Volume 970)
• Pages: 132-135
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.970.132
• Online since: June 2014
• Authors: Huseyin Kizil*, Meryem Oznur Pehlivaner, Levent Trabzon
• Keywords: Flexible Electronics, Plasma Surface Treatment, Polyimide

References

[1] S. H. Cho, S. H. Kim, N. -E. Lee, H. M. Kim and Y. W. Nam, Micro-scale metallization on flexible polyimide substrate by Cu electroplating using SU-8 photoresist mask, Thin Solid Films 475, (2005) 68-71.

DOI: 10.1016/j.tsf.2004.08.081

[2] K. Kim, K. R. Lee, W. H. Kim, K. -B. Park, T. -H. Kim, J. -S. Kim, and J. J. Pak, Polymer-based flexible tactile sensor up to 32x32 micron arrays integrated with interconnection terminals, Sensors and Actuators A: Physical 156, (2009) 284-291.

DOI: 10.1016/j.sna.2009.08.015

[3] Y. -S. Lin and H. -M. Liu, Enhanced adhesion of plasma-sputtered copper films on polyimide substrates by oxygen glow discharge for microelectronics, Thin Solid Films 516, 1773-1780 (2008).

DOI: 10.1016/j.tsf.2007.07.162

[4] D. L. Pappas, J. J. Cuomo, and K. G. Sachdev, Studies of adhesion of metal films to polyimide, J. of Vac. Sci. Technol. A 9 (5), (1991) 2704-2708.

[5] A. M. Ektessabi and S. Hakamata, XPS study of ion beam modified polyimide films, Thin Solid Films 377-378, 621-625 (2000).

DOI: 10.1016/s0040-6090(00)01444-9

[6] S. C. Park, S. S. Yoon, and J. D. Nam, Surface characteristics and adhesive strengths of metal on O2 ion beam treated polyimide substrate, Thin Solid Films 516, 3028-3035 (2008).

DOI: 10.1016/j.tsf.2007.11.113

[7] N. Inagaki, S. Tasaka, and M. Masumoto, Improved Adhesion between Kapton Film and Copper Metal by Plasma Graft Polymerization of Vinylimidazole, Macromolecules 29, 1642-1648 (1996).

DOI: 10.1021/ma9503571

[8] Y. -S. Lin, H. -M. Liu, and H. -T. Chen, Surface modification of polyimide films by argon plasma for copper metallization on microelectronic flex substrates, J. Appl. Polym. Sci. 99, 744-755 (2006).

DOI: 10.1002/app.22545

[9] Y. -S. Lin, H. -M. Liu, and C. -W. Tsai, Nitrogen plasma modification on polyimide films for copper metallization on microelectronic flex substrates, J. Polym. Sci. B Polym. Phys. 43, 2023-2038 (2005).

DOI: 10.1002/polb.20497

[10] S. -J. Park and H. -Y. Lee, Effect of atmospheric-pressure plasma on adhesion characteristics of polyimide film, Journal of Colloid and Interface Science 285, 267-272 (2005).

DOI: 10.1016/j.jcis.2004.11.062

[11] S. H. Kim, S. W. Na, N. -E. Lee, Y. W. Nam, and Y. -H. Kim, Effect of surface roughness on the adhesion properties of Cu/Cr films on polyimide substrate treated by inductively coupled oxygen plasma, Surface and Coatings Technology 200, 2072-2079 (2005).

DOI: 10.1016/j.surfcoat.2005.05.021
