Study on the Dynamic Weighing Measurement Accuracy of the No Parking Weight Charging System

Abstract:

In this paper, the intelligent weight charging system of heavy loaded highway was developed using piezoelectric quartz sensors, combined with the improved ETC system, in order to solve the congestion problem in highway toll station caused by heavy load vehicles. By study of the effects of different layout and spacing of sensors on the dynamic weighing accuracy and speed, then the optimal layout system of sensors was raised. Real vehicle test was carried out in Changwu charging station of highway from Fuzhou to Yinchuan. Experimental results show that: the optimized sensors enable heavy load vehicles passing through the toll stations in speed of 30km/h,and the accuracy of weighing was maintained within ± 2.5%. And the optimized sensors are able to overcome the errors caused by illegal operations, reaching the purpose of highway congestion management.

• Periodical: Advanced Materials Research (Volumes 971-973)
• Pages: 1347-1352
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.971-973.1347
• Online since: June 2014
• Authors: Hao Li*, Zhi Wei Gao, Xuan Cang Wang, Qiao Wei
• Keywords: Dynamic Weighing, Heavy Loaded Road, Piezoelectric Quartz Sensors, Road Engineering

References

[1] Yangji WEI, Wei ZHANG. Research on resettable toll system of Shaanxi highway (2011): 16-22.

[2] Xuancang WANG etc. Report of complete technical of intelligent weight charging of the overloaded roads (2010): 3-10.

[3] Qi SHENG, Dan WANG etc. Research on processing algorithm of axle load data of ETC vehicle dynamic weighing system (2009).

[4] Fei XU, Xinyou LI, Research and design of vehicle unit in ETC system (2011): 58-64.

[5] Chang WANG, Analysis and suppression of interference factors of dynamic weighing system (2011).

[6] Baoju WANG, Discussion of weighting fees dispute of highway (2011): 11-17.

[7] Min XIE, Analysis of features of new kinds of weight equipments (2011): 43-49.
