Sub-Synchronous Oscillation Caused by HVDC and the Damping Characteristic Analysis

Abstract:

Because of China's energy and load imbalance, respectively, large-scale long-distance power transmission becomes inevitable. Under this background , HVDC develops rapidly, SSO (Sub-synchronous oscillations) caused by HVDC is becoming increasingly apparent. The sub-synchronous electrical damping within the frequency range is difficult to calculate. Based on small-signal test method-complex torque coefficient method in the time-domain simulation , the paper calculated the sub-synchronous electrical damping characteristics of the system and analyzed the impact of the unit interaction, DC power and the generator output on sub-synchronous electrical damping characteristics.

• Periodical: Advanced Materials Research (Volumes 971-973)
• Pages: 1353-1356
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.971-973.1353
• Online since: June 2014
• Authors: Han Chen*, Chun Lin Guo, Qin Lei Chen
• Keywords: Complex Torque Coefficient Method, HVDC, Signal Testing Method, SSO Damping Characteristics, Sub-Synchronous Oscillation (SSO)

References

[1] Changchun Zhou: Study of SSO damping in the HVDC power system, Hang Zhou, ZhejiangUniversity, (2004).

[2] Zheng Xu, Ruiqun Luo, and Ruijin Zhu : Review On method of analysis for sub-synchronous oscillations of power systems, Zhejiang University, Power System Technology , Vol . 23(6) ( 1999), pp.36-39.

[3] Yixin Ni, Shousun Chen and Baolin Sun: Theory and analysis of dynamic power system[M]. Beijing, Tsing-hua University Press, (2002).

[4] Shijie Cheng, Yijia Cao and Quanyuan Jiang: The Method and damping method of power system sub-synchronous oscillation. Science Press.

DOI: 10.1109/icpst.2002.1053598

[5] IEEEStd1204-1997. IEEE guide for planning DC links terminating at AC locations having low short-circuit capacities. [R]. New York: IEEE PES , 1997, 82-89.

DOI: 10.1109/ieeestd.1997.85949

[6] Zheng Xu, The Complex Torque Coefficient Approach's Applicability Analysis and Its Realization by Time Domain Simulation[M]. Proceedings of the CSEE , Vol20(6), (2000).

[7] Changchun Zhou, Damping Analysis of Sub-synchronous Oscillation Caused By HVDC[M], Proceedings of the CSEE, Vol: 23(10), 2003, pp.6-10.

[8] Changchun Zhou , Zheng Xu Analysis of Damping Characteristic of the Sub-synchronous Oscillation in AC/DC Systems with Series Capacitor Compensation[M]. High Voltage Technology, Vol: 30(2), (2004).

[9] Canay I M. A novel approach to the torsional interaction and electrical damping of the synchronous machine, Part I: Theory, Part II: Application to an arbitrary network. IEEE Transaction on Power Apparatus and Systems, 1982, 101(10).

DOI: 10.1109/tpas.1982.317049
