Research on Calculation of Intersecting Line of Curved Pipes that Based on UG

Abstract:

In order to solve the problem in calculating the analytic equation of intersecting line which forms by two curved pipes, this paper presents a solution which based on UG. By employing UG we can extract the coordinates of discrete points of the intersecting line, then fit the discrete points with cubic B-spline curve, thus obtain the analytic equation. Finally, this paper verifies the feasibility of this method through simulation in Matlab, therefore, lays the theoretical basis for the development of flame cutting machine.

• Periodical: Advanced Materials Research (Volumes 971-973)
• Pages: 658-662
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.971-973.658
• Online since: June 2014
• Authors: Zhen Jie Zhang*, Guo Shun Ji, En Dao Xu, Ju Yong Zhang, Zhi Ping Chen
• Keywords: Cubic B-Spline Curve, Discrete Points, Intersecting Line, MATLAB, UG

References

[1] Yan Li: Space steel structure engineering application development[J]. Shanxi architecture, 2013, 39(36): 55-58.

[2] Zhong Ji, Ren Liu: Supervise intersecting mathematical model and its application in the numerical control processing[J]. Journal of Engineering Graphics, 2002(2): 139-144.

[3] Huijun Xiao, Jian Huang: NC cutting principle of a complex cylindrical intersecting lines[J]. Machine Tool & Hydraulics, 2003(4): 254-255.

[4] Juliang Xiao, Xiangan Yan, Guodong Wang: The research and simulation of NC flame cutting machine cutting torch path[J]. Chinese Journal of Mechanical Engineering, 2005, 41(4): 234-238.

DOI: 10.3901/jme.2005.04.234

[5] Jintao Tan, Jinghai Gong: The program design of pipe intersecting line with coordinate transformation method[J]. Sichuan Building Science, 2005, 31(6): 34-36.

[6] Wei Chen, Sumin Yin: Five-axis linkage CNC laser processing system in space curve B-spline interpolation algorithm research[J]. Machine Tool & Hydraulics, 2004(1): 53-55.
