Microstructure and Direct Measured Micro-Strain by TEM of Hot Iso-Static Pressed Alumina-Titanium Carbide (Al₂O₃-TiC) Composite

Abstract:

Alumina-titanium carbide composite (Al₂O₃-TiC) is one of advance ceramic matrix composites (CMC) that have been used in machining tool and tribology application because of its excellent mechanical properties. Powder processing is often a chosen method to produce this family of material, i.e. hot pressed (HP), hot iso-static pressed (HIP), and pressure-less sintering (PS). These manufacturing techniques convert sub-micron powder into dense bulk component. Al₂O₃-TiC composite has been prepared by HIP process, containing 65%vol Al₂O₃ and 35%vol TiC. The powders were pressured and sintered at temperature between 1250˚C - 1650˚C. Thermal residual stress from Al₂O₃-TiC manufacturing process is conventionally unavoidable. The aim of this study is to investigate the microstructure of HIPped Al₂O₃-TiC composite and its residual micro-strain using transmission electron microscopy (TEM) with selected area electron diffraction pattern (SADP) analysis. The Al₂O₃-TiC composite was prepared by high-precision machining/grinding processes then focus ion beam milling process was used to section the TEM lamella. Microstructures, grain size and phases were determined by TEM and X-ray diffractometry (XRD). Micro-strains of {200}TiC, {111}TiC , {220}TiC and {012}Al₂O₃ were investigated by SADP (Selected Area Diffraction Pattern). Our result revealed there is approximately 0.01 compressive strains distributed in Al₂O₃-TiC composite.

• Periodical: Advanced Materials Research (Volume 983)
• Pages: 156-160
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.983.156
• Online since: June 2014
• Authors: Sineenart Thumsoontorn, Surasak Kuimalee, Budsabong Kuntalue, Suphakit Pintasiri, Boonrat Lohwongwatana*
• Keywords: Al₂O₃-TiC Composite, AlTiC, FIB-TEM Sample Preparation, HIP, Micro-Strain

References

[1] K.F. Caia, D.S.M., N. Axenb, R. Manyatsab, Preparation, microstructures and properties of Al2O3–TiC composites. Ceramics International, 2001. 28(2002): p.7.

[2] Wilson Acchar, C.R., Ferreira da Cemara, et al., Mechanical performance of Alumina rainforced woth NbC, TiC, WC. Materials Research, 2012. 15(6): p.4.

[3] J. Echeberria, J.T., J.Y. H, Butler, F. Castro, Sinter-HIP of alpha-alumina powders with sub-micron grain sizes. Journal of the European Ceramic Society 2002(22): p.9.

DOI: 10.1016/s0955-2219(01)00510-6

[4] M.E. Fitzpatrick, M.T. Hutchings, and P.J. Withers, Separation of macroscopic, elastic mismatch and thermal expansion misfit stress in metal matrix composite quenched plates from nuetron diffraction. Acta metallurgica, 1997. 45(12): p.9.

DOI: 10.1016/s1359-6454(97)00209-7

[5] Withers, P.J. and H.K.D.H. Bhadeshia, Overview Residual stress Part 2 Nature and origins. Materials Science and Technology, 2001. 17(10): p.366.

DOI: 10.1179/026708301101510087

[6] Schmid, H.K., et al., Microstructural Characterization of Al2O3-SiC Nanocomposites. Journayl of European Ceramic Societ, 1998. 18: p.11.

[7] Guo, S., A. Limpichaipanit, and R.I. Todd, High resolution optical microprobe investigation of surface grinding stresses in Al2O3 and Al2O3/SiC nanocomposites. Journal of the European Ceramic Society, 2011. 31: p.13.

DOI: 10.1016/j.jeurceramsoc.2010.08.021

[8] Yao, N. and A.K. Epstein, Surface nanofabrication using focused ion beam, in FORMATEX. 2010, Microscopy Science, Technology, Applications and Education. p.10.
