Comparative Studies on Various Turbulent Models with Liquid Rocket Nozzle through Computational Tool

Abstract:

Supersonic flows associated with missiles, aircraft, missile engine intake and rocket nozzles are often steady. In this present work, the computational analysis was conducted on C-D (convergent –divergent) nozzle for understanding the flow regime with various flow properties such as velocity and various turbulent models (spalert almaras, K-ε and K-ω). The Scale down model of C-D nozzle was chosen for this study and it was modelled computationally with Gambit software package. In this integrated component model, the inlet flow is assumed a two-dimensional, steady, compressible, turbulent and supersonic. The physics based mathematical model of the considered flow consists of conservation of mass, momentum and energy equations subject to appropriate boundary conditions as defined by the physical problem stated above. The system of the governing equations with turbulent effects is solved numerically using different turbulence models to demonstrate their numerical accuracy in predicting the characteristics of turbulent gas flow in such complex geometry. Fluent software package was used for solving gas flow equations with turbulence models. The Mach number was chosen for different cases of analyses were 1.2, 1.5 and 2. For each case, different turbulence were engaged and solved and all the results were compared finally.

• Periodical: Advanced Materials Research (Volumes 984-985)
• Pages: 1204-1209
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.984-985.1204
• Online since: July 2014
• Authors: N.K. Mohamad Tanveer, Chandran Mohanraj*, K. Jegadeesan, S. Maruthupandiyan
• Keywords: Computational Fluid Dynamics (CFD), Supersonic Flow, Turbulence Model

References

[1] P. Padmanathan, Dr. S. Vaidya Nathan, Computational Analysis of Shockwave in Convergent Divergent Nozzle, International Journal of Engineering Research and Applications, Vol. 2, Issue 2, Mar-Apr 2012, pp.1597-1605.

[2] Ms.B. Krishna Prafulla, Dr. V. Chitti Babu 2 and Sri P. Govinda Rao, Cfd Analysis of Convergent- Divergent Supersonic Nozzle, International Journal of Computational Engineering Research, Vol, 03, Issue 5.

[3] Sibendu Soma, Anita I. Ramirez , Douglas E. Longman , Suresh K. Aggarwal, Effect of nozzle orifice geometry on spray, combustion, and emission characteristics under diesel engine conditions, journal homepage: www. elsevier. com/locate/fuel.

DOI: 10.1016/j.fuel.2010.10.048

[4] Seyed Ehsan Rafiee, Masoud Rahimi, Experimental study and three-dimensional (3D) computational fluid dynamics(CFD analysis) on the effect of the convergence ratio, pressure inlet and number of nozzle intake on vortex tube performance Validation and CFD optimization, Energy, Volume 63, 15 December2013, Pages195-204.

DOI: 10.1016/j.energy.2013.09.060

[5] A. Balabel, A.M. Hegab, M. Nasr, Samy M. El-Behery, Assessment of turbulence modeling for gas flow in two-dimensional convergent divergent rocket nozzle, Applied Mathematical Modelling, Volume35, Issue7, July2011, Pages3408-3422.

DOI: 10.1016/j.apm.2011.01.013

[6] K. Pougatch, M. Salcudean, E. Chan, B. Knapper, Modelling of compressible gas–liquid flow in a convergent divergent nozzle, Chemical Engineering Science, Volume 63, Issue 16, August 2008, Pages 4176-4188.

DOI: 10.1016/j.ces.2008.05.027

[7] Y. Bartosiewicz, Zine Aidoun, CFD-Experiments Integration in the Evaluation of Six Turbulence Models for Supersonic Ejectors Modeling, CETC-Varennes, Natural Ressources Canada, ybartosi@RNCan. gc. ca.

[8] C. Mohanraj, Dr.P.K. Srividhya, CFD Simulation of 20 kW Downdraft Gasifier, International Journal of Current Engineering and Technology ISSN 2277 - 4106, Vol. 3, No. 1 (March 2013).

[9] K.M. Pandey, Virendra Kumar, Prateek Srivastava, CFD Analysis of Twin Jet Supersonic Flow with Fluent Software, Current Trends in Technology and Sciences Volume 1, Issu 2 , (Sept. -2012).

[10] Biju Kuttan P, M Sajesh, Optimization of Divergent Angle of a Rocket Engine Nozzle Using Computational Fluid Dynamics, The International Journal Of Engineering And Science (Ijes), Volume2, Issue 2, Pages196-207, (2013).

[11] Nadeem Akbar Najar, D Dandotiya, Farooq Ahmad Najar, Comparative Analysis of K-ε and Spalart-Allmaras Turbulence Models for Compressible Flow through a Convergent-Divergent Nozzle, The International Journal Of Engineering And Science (IJES), Volume2, Issue8, Pages08- 17, (2013).

[12] Pardhasaradhi Natta, V. Ranjith Kumar, Dr.Y.V. Hanumantha Rao, Flow Analysis of Rocket Nozzle Using Computational Fluid Dynamics (Cfd), Engineering Research and Applications (IJERA) ISSN 2248-9622 , Vol. 2, Issue 5, September- October 2012, pp.1226-1235.
