DWT Based Automated Weld Pool Detection and Defect Characterisation from Weld Radiographs

Abstract:

Industrial Radiography is the most widely accepted NDT technique for weld quality in industries. As it is an indirect method, defect type and nature must be obtained by analyzing the radiographs. Manual interpretation of radiographs is subjective in nature. So the paradigm shifted to automated weld defect detection system. Though considerable research is done in automated weld defect detection, an accurate domain specific technique has not yet been evolved due to noise, artifacts in radiographs, low contrast between the defect region and the background and difficulty in isolating the defect. The proposed work aims at developing an automated weld defect detection system that enhances the contrast between the object and the background and isolates the weld defect. In this work, real time weld radiographs are acquired and contrast enhancement is performed with DWT. Slag and Porosity are isolated and dimensionally characterized.

• Periodical: Advanced Materials Research (Volumes 984-985)
• Pages: 573-578
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.984-985.573
• Online since: July 2014
• Authors: K. Sudheera*, N.M. Nandhitha, Lakshmi Mohanachandran, Parithosh Nanekar, B. Venkatraman, B.Sheela Rani
• Keywords: DWT, Porosity, Radiographs, Slag, Weld

References

[1] Ioannis Valavanis, and Dimitrios Kosmopoulos, Multiclass defect detection and classification in weld radiographic images using geometric and texture features, Expert Systems with Applications , , vol. 37, pp.7606-7614, (2010).

DOI: 10.1016/j.eswa.2010.04.082

[2] Mythili Thiruganam, Dr.S. Margret Announcia, Sachin Kantipudi, Automatic Defect Detection and Counting in Radiographic Welding Images, International Journal of Computer Applications(0975-8887), , volume 10-No. 2, pp.1-5, (2010).

DOI: 10.5120/1457-1971

[3] Sara Saber, Gamal I. Selim, Higher –Order Statistics for Automatic Weld Defect Detection, Journal of software Engineering and Applications, , 2013, 6 , 251-258, doi: 10. 4236/jsea. 2013. 65031.

DOI: 10.4236/jsea.2013.65031

[4] Vijay R. Rathod and R.S. Anand, NDE weld defect detection and feature extraction using segmentation approach, International Journal Advanced Intelligence Paradigms, , Vol. 3, Nos. 3/4, (2011).

DOI: 10.1504/ijaip.2011.043432

[5] M. Ghazvini, S. A. Monadjemi, N. Movahhedinia, and K. Jamshidi, Defect Detection of Tiles Using 2D-Wavelet Transform and Statistical Features", World Academy of Science, Engineering and Technology, 49, , pp.901-904, (2009).

[6] Yuan Li, You Fu Li, Qing Lin Wang, De Xu, Min Tan, Measurement And Defect Detection Of The Weld Bead Based On Online Vision Inspection", IEEE transactions on Instrumentation And Measurement, , Vol. 59, No. 7, July (2010).

DOI: 10.1109/tim.2009.2028222
