Effects of Tool Pin Profile and Tool Shoulder Diameter on the Tensile Behaviour of Friction Stir Welded Joints of Aluminium Alloys

Abstract:

— For fabricating light weight structures, it requires high strength-to weight ratio. AA6061 aluminium alloy is widely used in the fabrication of light weight structures. A356 aluminium alloy has wide spread application in aerospace industries. Friction stir welding is solid state joining process which is conducting for joining similar and dissimilar materials. The friction stir welding parameters play an important role for deciding the strength of welded joints. In this investigation, A356 and AA6061 alloys were friction stir welded by varying triangular, square, hexagonal pin profiles of tool keeping the remaining parameters same and AA6061 alloys were friction stir welded by varying tool shoulder diameter as 12mm,15mm,18mm without changing other parameters. Tensile properties of each joint have been analyzed microscopically. From the experimental results, it is observed that hexagonal pin profiled tool and 15mm shoulder diameter tool provides higher tensile properties when compared to other tools.

• Periodical: Advanced Materials Research (Volumes 984-985)
• Pages: 586-591
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.984-985.586
• Online since: July 2014
• Authors: R. Ashok Kumar*, M.R. Thansekhar
• Keywords: A356 Aluminum Alloy, AA6061 Aluminum Alloy, FSW, Tensile Strength

References

[1] Matrukanitz RP, Selection and weldability of heat-treatable aluminum alloys. ASM Handb – WelBraz Sold 1990; 6: 528–36.

[2] Chen YC, Nakata K. Effect of the surface state of steel on the microstructure and mechanical properties of dissimilar metal lap joints of aluminum and steel by friction stir welding. Met Mater Trans A 2008; 39A: 1985–92.

DOI: 10.1007/s11661-008-9523-4

[3] Ma ZY, Friction stir processing technology: a review. Metall Mater Trans A2008; 39A: 642–58.

[4] K. Elangovan, V. Balasubramanian, S. Babu, Predicting tensile strength of friction stir welded AA6061 aluminium alloy joints by a mathematical model (2009) 188-193.

DOI: 10.1016/j.matdes.2008.04.037

[5] K. Elangovan, V. Balasubramanian, Influences of tool pin profile and tool shoulder diameter on the formation of friction stir processing zone in AA6061 aluminium alloy (2008) 362-373.

DOI: 10.1016/j.matdes.2007.01.030

[6] S. Malarvizhi, V. Balasubramanian, Influences of tool shoulder diameter to plate thickness ratio (D/T) on stir zone formation and tensile properties of friction stir welded dissimilar joints of AA6061 aluminum–AZ31B magnesium alloys (2012).

DOI: 10.1016/j.matdes.2012.04.008

[7] M. Ghosh, K. Kumar, S.V. Kailas, A.K. Ray, Optimization of friction stir welding parameters for dissimilar aluminum alloys (2010) 3033-3037.

DOI: 10.1016/j.matdes.2010.01.028
