Effect of Process Parameters during Friction Stir Welding of Al 6063 Alloy

Abstract:

In the Present paper, the effects of axial force, rotational speed of the FSW tool, welding speed and shoulder penetration on various mechanical properties of Aluminium alloy 6063 butt joint produced by Friction Stir Welding have been analyzed. The mechanical properties like tensile strength, Yield strength and % Elongation have been tested using 6 mm thickness plate. The tool used for conducting the experiment was Hot Die Steel (HDS). The welding quality can be improved by enhancing the mechanical properties and minimizing the defects. Hence, analysing & examining the mechanical or physical properties and other relevant significant factors would help to enhance the weld reliability. Tensile Strength (TS), Percentage of Elongation & Yield Strength (YS) of FSW Al 6063 alloy has been carried out under different processing condition using Taguchi’s experimental design. An optimum result has been obtained using main effects plot using S/N ratio values. The rotation speed of the FSW tool has been found dominant factor for TS followed by feed and shoulder penetration. Shoulder diameter shows the least effect on TS compared to parameters like Percentage of Elongation & Yield Strength (YS).

• Periodical: Advanced Materials Research (Volumes 984-985)
• Pages: 604-607
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.984-985.604
• Online since: July 2014
• Authors: V. Jaiganesh*, P. Sevvel
• Keywords: % Elongation, Al6063 Aluminium Alloy, Tensile Strength, Yield Strength

References

[1] Kim JK, Lee BJ, Lee BH, Kim YH, Kim KY (2009) Intergranular Segregation of Cr in Ti-stabilized low-Cr ferritic stainless steel. Scripta Mater. v. 61, p.1133.

DOI: 10.1016/j.scriptamat.2009.08.045

[2] E.T. Akinlabi, A. Els-Botes, and H. Lombard. Effect of tool displacement on defect formation in friction stir welding of aluminium and copper,. In Proceedings of the 8th International Friction StirWelding Symposium, Hamburg, Germany, May 18 – 20, (2010).

[3] Živković, A., Influence of Friction Stir Welding Tool Geometry on Properties of Welded Joint of Alloys Al 2024 T351 (in Serbian), Ph. D. thesis, Faculty of Mechanical Engineering, University of Belgrade, Belgrade, Serbia, (2011).

[4] Rajakumar S, Balasubramanian V (2011) Predicting tensile strength, hardness and corrosion rate of friction stir welded AA 6061–T6 aluminium alloy joints. Materials & Design, Vol. 32, Issue. 52878-2890.

DOI: 10.1016/j.matdes.2010.12.025

[5] Elangovan K, Balasubramanian V, Babu S (2009) Predicting tensile strength of friction stir welded AA6061 aluminium alloy joints by a mathematical model. Materials and Design, Volume 30, issue 1, pp.188-193.

DOI: 10.1016/j.matdes.2008.04.037

[6] Muhsin J.J., Moneer H. Tolephih, and Muhammed A. M (2012).

[7] P. Janaki Ramulu etal., (2012) Internal defect and process parameter analysis during friction stir welding of Al 6061 The International Journal of Advanced Manufacturing Technology, Volume 65, Issue 9-12, pp.1515-1528.

DOI: 10.1007/s00170-012-4276-z

[8] Pouya Bahemmat & Mohammad Haghpanahi & Mohammad Kazem Besharati Givi & Kambiz Reshad Seighalani (2011).

[9] Edward G. Cole & Axel Fehrenbacher & Edward F. Shultz & Christopher B. Smith & Nicola J. Ferrier & Michael R. Zinn & Frank E. Pfefferkorn, Stability of the friction stir welding process in presenceof workpiece mating. The International Journal of Advanced Manufacturing Technology, 2012, Volume 63, Issue 5-8, pp.583-593.

DOI: 10.1007/s00170-012-3946-1

[10] Kanwer S. Arora & Sunil Pandey & Michael Schaper & Rajneesh Kumar, Effect of process parameters on friction stir welding of aluminum alloy 2219. The International Journal of Advanced Manufacturing Technology, Volume 50, Numbers 9-12, 2010, pp.941-952.

DOI: 10.1007/s00170-010-2560-3

[11] P. Sevvel & V. Jaiganesh, A detailed examination on the future prospects of friction stir welding –A green technology,. In the proceeding of the Second International Conference on Advances in Industrial Engineering Applications, ICAIEA, Anna University, Chennai, Tamilnadu, 6-8th Jan, (2014).
