Evaluation of On-Line DGA Limit Values and Calculation of Detecting Intervals for On-Line Monitoring Equipment for Transformers

Abstract:

Methods presented in this paper evaluate the on-line DGA results and provide specific on-line DGA limit values. For on-line equipment monitoring transformer condition, a method to calculate specific detecting intervals according to the evaluation of on-line DGA results is proposed. An example to calculate detecting intervals is demonstrated using the field test data acquired by on-line equipment for transformer condition-monitoring service.

• Periodical: Advanced Materials Research (Volumes 986-987)
• Pages: 1643-1646
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.986-987.1643
• Online since: July 2014
• Authors: Yang Liu Li*, Zhi Yong Chen
• Keywords: Detecting Intervals, DGA, Limit Values, On-Line Detection
