Detection on the Pulse Signal of Human Body Based on Piezoelectric Impedance Technique

Abstract:

Pulse wave is one of important physiological characters of human body. Detection on pulse sign is helpful for health care and treatment of disease. In order to detect the change of pulse signal of human body, the work principle of detection based on the piezoelectric impedance technique was presented and a new piezoelectric impedance sensor was designed. With an experiment platform set up, detection experiments of pulse signal were created. Two methods were used to deal with the experimental data. Results from a series of experiments intuitively show that with pressure applied to human body bigger and bigger, the pressure index increases gradually. It illustrates that the change of pulse signal is bigger and bigger. The result indicates that this method has good sensitivity and provides a new detection method. The experiment shows that the piezoelectric impedance technique is feasible to detect the change of pulse sign.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 1120-1124
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.1120
• Online since: July 2014
• Authors: Jun Zhang*, Bang Zeng Guo, Hong Mei Tang
• Keywords: Physical Sign, Piezoelectric Effect, Piezoelectric Impedance Sensor, Pressure Index, Pulse Wave

References

[1] Xu Tao. Research on extraction and recognition method of the human pulse condition [D]. Shandong University of Science and Technology, (2008).

[2] Yu Lu. Research and Application of Pulse Signal Processing Methods Based on Virtual Instrument [D]. China Medical University, (2009).

[3] Ren Chengcheng. Design of the pulse sensor based on the PVDF piezoelectric film [D]. Dalian university of technology, (2011).

[4] Cheng Chao. A Development of the Simultaneous Acquisition System of ECG Signal and Pulse Wave. College of Bioengineering, South-Central University for Nationalities. (2011).

[5] Ren Kai. Analysis on Chinese medicine pulse signal based on the LabVIEW [D]. Changchun University of Science and Technology, (2012).

[6] Wang Guoli. Research on intelligent pulse signal testing system [D]. Shandong University, (2005).

[7] Chen Jie, Huang Hong. Sensor and detecting technology [M]. Higher education press, (2002).

[8] Tao Juan. The study of structure health diagnosis based on the EMI and the ANN technology. Anhui University of Science and Technology. (2013).

[9] Gao Qin. The Research of Piezoelectric Impedance Technology Applying to the Dynamic Signal Beam. Anhui University of Science and Technology. (2012).
