Accurate Calculation Receiving Power of the Electromagnetic Wave Scattering between Two Stations on Sea Surface

Abstract:

This paper studies receiving power of electromagnetic wave scattering on sea surface transmitted by directional antenna. Analyzes different overlapping conditions of transmitter beaming and receiver beaming on the sea surface, deduces the calculation formulae, and calculation of the receiving power of scattering wave in case of different across angle between radiator and receiver beams on sea surface. The result shows that the across angle is a important factor of receiver to receive electromagnetic wave scattering power on sea surface, and it gives an accurately calculating method by receiver to receive electromagnetic wave scattering power from sea surface. The method can apply to the condition that radar or jammer transmitters beam to sea surface and reconnaissance or radar receiving the scattering power from sea surface at another position, etc..

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 1135-1140
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.1135
• Online since: July 2014
• Authors: Xian Mao Li*, Tian Lin Dong, Gao Ming Huang
• Keywords: Beaming Area, Double Stations, Electronic Reconnaissance, Receiving Power, Sea Surface Scattering

References

[1] Smith, J.R., Jr.; Burkholder, R.J. Channeling phenomenon in electromagnetic forward scattering at low grazing [J]. Geoscience and Remote Sensing, IEEE Transactions on, 2004 (8) 1731 - 1738.

DOI: 10.1109/tgrs.2004.831694

[2] Soriano G., Guerin C., Saillard M. Microwave ocean scattering at low-grazing angles with the GmoM[C]. Proceedings of the 7th European Radar Conference, 2010 5-8.

[3] Jerry R. Smith, Jr. Robert J. Burkholder . Channeling Phenomenon in Electromagnetic Forward Scattering at Low Grazing. Geoscience and Remote Sensing, IEEE Transactions on, 2004 (8) 1731-1738.

DOI: 10.1109/tgrs.2004.831694

[4] Smith, J.R. ; Russell, S.J. ; Brown, B.E. etc. Electromagnetic forward-scattering measurements over a known, controlled sea surface at grazing. Geoscience and Remote Sensing, IEEE Transactions on, 2006 (42) 1197-1207.

DOI: 10.1109/tgrs.2004.826783

[5] Xuguang YAN, Fuyuan PENG, Guohua XU , Xutao LI. Ana lysis of tempora l and frequency character istics of fore2sca ttered la ser in ocean channel. Laser Technology 2005 (3) 266-269.

[6] Tao ZHANG, Qun ZHANG, Binfeng LUO, Shouhong ZHANG. Shadow Imaging for Bistatic Radar Ba sed on Forward Scattering by Joint Time Frequency Analysis. ACTA ELECTRONICA SINICA, 2001 (6) 726-729.

DOI: 10.1049/cp.2009.0143

[7] Rongrong WANG, Fang LIU. Study on the Backsca tter ing Enhancement of 22D Sea Surface with the Sta tionary Pha seMethod. Journal of Xinyang Normal University: Natural Science Edition. 2010 (6) 219-226.

[8] LIU Da1, HAN Xiao bing, FANG Long. The Research and Implementation of 3-Dimensional Cartesian Coordinate System Direct Conversion Algorithm[J]. Geomatics & Spatial Information Technology, 2012 (5) 175-182.

[9] Guoyu Wang, Lian-dong Wang, etc. Digital Simulation And Evaluation of Radar EW System [M]. Beijing: National Defence Industry Press, pp.85-86, (2004).

[10] Wanhai Yang. Modeling and Simulation of Radar System [M]. Sian: Xidian University Press, 2007 157.

[11] Qixiao Ye, Yonghuan Shen. Applied Math Manual (Second Press) [M]. Beijing: Science Press, 2006 65-70.

[12] Math Manual Compile Group. Math Manual [M]. Beijing: Higher EducationPress, 1979 349-354.
