Impact of Tooth Shape Parameters on Strength Safety Coefficient of Herringbone Planetary Train

Abstract:

The influence of tooth profile parameters on the strength safety coefficient can provides the basis for the design of high strength herringbone planetary train system. Through calculation of the three strength safety coefficients (contact strength, bending strength, bonding strength), curves of the relationships between the tooth shape parameters (addendum coefficient, tip clearance coefficient, spiral angle) and the strength safety coefficients have been obtained and the impact of tooth shape parameters on the three strength safety coefficients have been analyzed. The research results show that the bigger addendum coefficient can be selected for the design of high strength herringbone planetary train system. In order to satisfy bending strength, no-undercut and lubrication condition the smaller tip clearance coefficient should be taken. The strength safety coefficients are bigger with the increase of spiral angle, so a bigger spiral angle may be appropriately chosen.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 2753-2757
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.2753
• Online since: July 2014
• Authors: Zeng Bao Zhu*, Chao Qun Shu, Ying Li Xu, Can Li, Min Yin
• Keywords: Herringbone, Planetary Train, Strength Safety Coefficient, Tooth Profile Parameter

References

[1] (Japan) Namigasenshou: Gear design of high strength [M]. Machinery Industry Press, (1981).

[2] Andrzej K, Jerzy W, Dariusz C. Comparative Analysis of Tooth-Root Strength Using ISO and AGMA Standards in Spur and Helical Gears With FEM-based Verification [J]. ASME J. Mech. Des , 2005, 128(5): 1141-1158.

DOI: 10.1115/1.2214735

[3] Jinglong Hung, Xiexing Miu, Shanming Luo, etc: Impact of teeth pressure angle on gear strength in analysis [J]. Machine Design and Research, 2007, 34(7): 9-15. (In Chinese).

[4] Dongan Zhan, Yunxiao Fan, Junru Yan: Choice of lead angle and design of tooth direction high speed of helical gears [J]. Journal of Shandong University of Science and Technology, 2000, 19(3): 67-69. (In Chinese).

[5] Yin Wang, Sanmin Wang, Hui Wang: Impact of high-speed heavy helical gears transmission parameters on performance research [J]. Journal of Mechanical Transmission, 2012, 36(7): 21-26. (In Chinese).

[6] National Standards Institute. GB 3480—83 calculation methods of load capacity for in volute cylindrical gears [S]. Beijing: National Standards Institute, 1983. (In Chinese).

[7] National Standards Institute. GB 3480—86 calculation methods of scuffing load capacity for in volute cylindrical gears [S]. Beijing: National Standards Institute, 1986. (In Chinese).

[8] Zengbao Zhu, Rupeng Zhu, Yingsheng Li, etc: Impact of mesh stiffness on dynamic load characteristics of herringbone planet train [J]. Acta Armamentarii, 2013, 34(6): 732~738. (In Chinese).

[9] Wensheng Peng, Zhiming Li, Hualiang Huang: Design of machinery (second edition) [M]. Higher Education Press, 2008. (In Chinese).
