Experimental Study on Active Vibration Control of Flexible Manipulator Based on Improved PPF Algorithm

Abstract:

The positioning accuracy and work efficiency of flexible manipulator is seriously affected by its vibration. Therefore, vibration control of single joint flexible manipulator is studied by using an improved PPF algorithm based on LabVIEW and piezoelectric technology. Firstly, the improved PPF algorithm principle is introduced. Then, the experiment process is discussed in detail. Experimental result shows that the improved PPF algorithm can effectively control the first two modal vibration of flexible manipulator. The control effect is close to 14 dB and improved nearly 4.5 dB compared with PPF algorithm.

• Periodical: Advanced Materials Research (Volumes 989-994)
• Pages: 2774-2777
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.989-994.2774
• Online since: July 2014
• Authors: Fei Du*, Tian Bing Ma
• Keywords: Direct Velocity Negative Feedback, Flexible Manipulator, Piezoelectric, Positive Position Feedback, Vibration Control

References

[1] Wang Zongli, Lin Qirong, Liu Zhengxing: State Dependent LQR Vibration Control for Piezoelectric Intelligent Beam [J]. Journal of Shanghai Jiaotong University, 2001, 35(4): 503-508.

[2] Qiu Zhicheng. Study on Variable Structure Vibration Control for Flexible Manipulator [J]. Journal of Dynamics and Control, 2007, 5(1): 62-67.

[3] QIU Zhicheng , XIE Cunxi , ZHANG Honghua , WU Hong-xin. Active Vibration Control for Flexible Piezoelectric Manipulator [J]. Robot, 2004, 26(1): 45-48.

[4] Song G, Schmidt S P, Agrawal B N. Active Vibration Suppression of a Flexible Structure Using Smart Materialand a Modular Control Patch[J]. Proceedings of the Institution of Mechanical Engineers, Part G, 2000, 214(4): 217-229.

DOI: 10.1243/0954410001532024

[5] Wang Bo, Improvement Methods for Vibration Control of Piezoelectric Intelligent Structures[D]. Chong Qing: Chongqing University, (2004).

[6] Ma Tianbing, Qiu Jinhao, Ji Hongli, Yuan Ming. Local Strain Compensation and Improved PPF Algorithm for Vibration Control[J]. Journal of South China University of Technology(Natural Scienca Edition), 2012, 40(5): 41-45.

[7] Xiong Shibo, Huang Changyi. Mechanical engineering testing technology[M]. Bei jing: CHINA MACHINE PRESS, (2009).

[8] Rew KeunHo, Han JAEHung, Lee In. Multi-modal vibration control using adaptive positive position feedback[J]. Journal of Intelligent Material Systems and Structures, 2002, 13(1): 13-22.

DOI: 10.1177/1045389x02013001866

[9] Wu Haoyi. Research of Active Control Method for Piezo-smart Cantilever Beam[D]. Da Lian: Dalian University of Technology, (2012).
